Research on Construction of Visual Platform of Beijing Power Grid Based on Multi-Technology Fusion

Abstract:

The platform uses three-dimensional data modeling, visual simulation and spatial data storage to make the business of regulation center, operation and maintenance center and marketing and management center of Beijing Power grid implement visualized operation, and load the spatial information data, equipment data and operation data of Beijing power grid into the system platform, and the data is displayed with the form of graphic or image, which not only realizes managing space resource data in real three-dimensional scene, but also make the system operator to know the operation state of the system directly, and makes the control measures more effective. And the paper uses virtual reality technology to establish visual scene of ground to realize integrated visual display of power transformation, power transmission and power distribution, which not only makes the producers, managers and decision makers directly master the situation of production line in power station, but also realizes that producers and managers affiliate decision makers to formulate production plan.

• Periodical: Applied Mechanics and Materials (Volumes 608-609)
• Pages: 928-932
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.608-609.928
• Online since: October 2014
• Authors: Dong Ya Jin*
• Keywords: Substation, Visual

References

[1] Zhu Tao, Observation on intelligent power grid and key techniques , Yunnan Electric Power, 2009, 37(4): 18-19.

[2] Xie Dihui, Yang Yueping, Research and application of intelligent electricity information interaction platform , Mechanical and Electrical Information, 2012, (6): 31-32.

[3] Ci Xiangyang, Influence of intelligent power grid construction on electric power operation modes in China , East China Electric Power, 2010, (3): 329-331.

[4] Gong Qingwu, Jiang Fangfang, Chen Yifei, Simulation training system of substation based on virtual reality technology , Power System Technology, 2005, (24): 1-5.

[5] Lin Xiaoming, Guo Jinli, Xiao Yong, Research on enhancing power demand side management in intelligent power grid construction ,  Science and Technology Innovation Herald, 2011, (22): 46-48.
