Application of Optical Fiber Sensing Real-Time Monitoring Technology Using in Ripley Landslide

Abstract:

Nowadays, fiber optic technology has been used in sensing. Using the distributed optical fiber sensing technology in the landslide monitoring, the linear strain distribution information of the whole landslide can be obtained, and adopting the Fiber Bragg Grating sensing technology in the landslide monitoring, the key pot strain and displacement information can be gained. This paper firstly reviews the basic principle of optical fiber sensing, and then describes the optical fiber sensing real-time monitoring system by combining with FBG technology, BOTDR technology, database technology and web server technology, and finally presents a field application experiment using the real-time monitoring system in Ripley landslide in Canada. The experiment indicated that the real-time monitoring system can be realized real-time monitoring of FBG and BOTDR for landslide, and the experience can be extended to other landslide.

• Periodical: Applied Mechanics and Materials (Volume 610)
• Pages: 199-204
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.610.199
• Online since: August 2014
• Authors: Xiao Fei Zhang, Zhong Hu Lv*, Xian Wei Meng, Fan Jiang, Qing Zhang
• Keywords: BOTDR, FBG, Optical Fiber Sensing, Real-Time Monitoring

References

[1] A.D. Kersey, M.A. Davis, H.J. Patrick, et al. 1997. Fiber Grating Sensors. Journal of Light-wave Technology 9: 76-79.

[2] Ansari, F. 2003. Fiber optic health monitoring of civil structures [A]. Structural Health Monitoring and Intelligent Infrastructure [C]. Japan: A A BALKEMA PUBLISHERS: 11-30.

[3] Hiroshige Ohno, Hiroshi Naruse, Mitsuru Kihara, et al. 2001. Industrial applications of the BOTDR optical fiber strain sensor [J]. Optical Fiber Technology 7: 45-64.

DOI: 10.1006/ofte.2000.0344

[4] Bao, X. DeMerchant M. Brown, A. 2001. Tensile and compressive strain measurement in the lab and field with the distributed Brillouin scattering sensor [J]. Lightwave Technology 19(1): 698-704.

DOI: 10.1109/50.964070

[5] Bin Shi, Hongzhong Xu, Dan Zhang, et al. 2004. Feasibility study on application of BOTDR to health monitoring for large infrastructure engineering [J]. Chinese Journal of Rock Mechanics and Engineering 23 (3): 493- 499.

[6] Xianwei Meng, Qing Zhang, Yanxin Shi, et al. 2010. The optical grating fiber sensing technology be used in geological hazards monitoring[C]. Near-Surface Geophysics and Geohazards-Proceedings of the 4~(th) International Conference on Environmental and Engineering Geophysics(Volume 2).

[7] Zhang Xiaofei, Hao Wenjie, Zhang Qing, et al. 2011. Development of Optical Fiber Strain Monitoring System Based on BOTDR[C]. Proceedings of IEEE 2011 10th International Conference on Electronic Measurement & Instruments(ICEMI'2011) VOL. 04.

DOI: 10.1109/icemi.2011.6037942
