Design of a Gain-Boosted Cascode Amplifier with High Unity-Bandwidth

Abstract:

This paper presents a high unity gain bandwidth fully differential folded-cascode operational amplifier using gain-boosted technique. The amplifier is designed in TSMC 0.18μm 1P6M CMOS technology. The unity-gain bandwidth (GBW) and poles of the gain-boosting amplifiers were carefully designed to improve the stability. The implemented design provides a direct current (DC) gain of around 93 dB with a unity gain frequency of 1.8GHz. It exhibits a DC gain larger than 88dB when the output common-mode voltage between 0.6 V and 1.2V. the overall layout size is 96μm×120μm.

• Periodical: Applied Mechanics and Materials (Volume 614)
• Pages: 237-240
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.614.237
• Online since: September 2014
• Authors: Lin Feng Wang*, Qiao Meng, Hao Zhi
• Keywords: Amplifier, Cascode Amplifier, Gain-Boosted, Switched-Capacitor Common Feedback

References

[1] D.Y. Chang, U.K. Moon:, IEEE J. Solid-State Circuits, Vol. 38(2003), pp.1401-1404.

[2] S. Limotyrakis. S, D. Kulchycki, D.K. Su, B. A. Wooley: IEEE J. Solid-State Circits, Vol. 40 (2005) , p.1057.

[3] S. Li, Q. Yulin: In Electron Devices and Solid-State Circuits, IEEE Conference(2005), p.441.

[4] K. Bult, G. Geelen: IEEE Journal of solid-State Circuits. Vol. 25(1990), p.1379.

[5] K. Nagaraj, H. S. Fetterman: IEEE J. Solid-State Circuits. Vol. 32 (1990), p.3.

[6] M. Banu, J. M. Khoury, and Y. Tsividis: IEEE J. Solid-State Circuits. Vol. 23 (1998), p.1410.

[7] Y. Yang. M. David : IEEE Circuits and Systems. Vol. 53 (2010), 33.

[8] Narendra Nath, R. Todani, C. Handrima: IEEE Conference on Information and Communication Technologies (2013).
