Compact 2X2 Optical Switch Using Silicon Photonics Technology for Optical Beam Forming Network

Abstract:

We report the experimental demonstration of a 2×2 electro-optical switch in silicon-on-insulator. By controlling electro-optical phase shifter, light from any input waveguide can be directed to any output waveguide. Furthermore, the proposed optical switch can be expanded to be 1×N and N×N optical switch for optical beam forming network. The switch is fabricated by CMOS technology. In experiment, full 2×2 switching functionality is demonstrated at wavelength of 1.55 μm, with an average crosstalk of-14.6 dB and compact size of 300X100 um2.

• Periodical: Applied Mechanics and Materials (Volume 614)
• Pages: 233-236
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.614.233
• Online since: September 2014
• Authors: Wan Jun Wang*, Heng Zhao, Wei Feng Guo, Hai Feng Shao, Ting Hu, Hui Ye Qiu, Jie Zhou, Nai Di Cui, Guo Wei Cao, Jun Wang, Jun Bo Feng, Jin Guo
• Keywords: Optical Beam Forming Network (OBFN), Optical Switch, Photonic Integrated Circuit, Silicon Photonics

References

[1] C. G. H. Roeloffzen, L. Zhuang, C. Taddei, A. Leinse, R. G. Heideman, P. W. L. van Dijk, R. M. Oldenbeuving, D. a I. Marpaung, M. Burla, and K. -J. Boller, Silicon nitride microwave photonic circuits., Optics express, vol. 21, no. 19. p.22937–61, 23-Sep-(2013).

DOI: 10.1364/oe.21.022937

[2] J. C. I. Gasulla, J. Lioret, J. Sancho, S. Sales, Recent Breakthroughs in Microwave Photonics, IEEE Photonics J., vol. 3, no. 2, p.311–315, (2011).

DOI: 10.1109/jphot.2011.2130517

[3] W. van E. Leimeng Zhuang, Chris G. H. Roeloffzen, Arjan Meijerink, Maurizio Burla, David A. I. Marpaung, Arne Leinse, Marcel Hoekman, René G. Heideman, Novel Ring Resonator-Based Integrated Photonic Beamformer for Broadband Phased Array Receive Antennas—Part II: Experimental Prototype, J. Light. Technol., vol. 28, no. 1, p.19–31, (2010).

DOI: 10.1109/jlt.2009.2032137

[4] M. L. J. Cardenas, S. Manipatruni, N. Sherwood-Droz, C. B. Poitras, B. Zhang, J. B. Khurgin, P. A. Morton, Large tunable delay of an RF photonic signal with 130 GHz bandwidth using silicon microresonators. pdf, in CLEO, 2010, p. CWG3.

DOI: 10.1364/cleo.2010.cwg3

[5] H. Lee, T. Chen, J. Li, O. Painter, and K. J. Vahala, Ultra-low-loss optical delay line on a silicon chip., Nat. Commun., vol. 3, p.867, Jan. (2012).

DOI: 10.1038/ncomms1876

[6] D. Kwong, Y. Z. Liu, A. Hosseini, Y. Zhang, B. Lee, C. Lin and R. T. Chen, Silicon-integrated photonic circuit for a single-stage large-angle beam steering optical phased array, in SPIE, 2010, p.760713–1.

DOI: 10.1117/12.843833

[7] R. A. Sored and B. R. Bennett, Electro-optical effects in silicon, J. Quantum. Electron. QE-23, 123-129 (1987).
