Application Analysis on Drawing Device of Differential Thread

Abstract:

In the field of mechanical installation and repairing, drawing devices are often used to disassemble or push up components of various types of axie and set. Differential thread usually consists of two sets of threads, which differ in the aspect of side pitch, the movement distance of differential thread when it runs a circle should be the deviation of the two spiral side pitches. Through the application of differential thread, it enables us to make changes in the transmission of these two screw pairs making relative movement. Based on this principle, when it is made into the application of manual drawing device, it optimized structure of drawing device, receiving a better result.

• Periodical: Applied Mechanics and Materials (Volume 614)
• Pages: 565-568
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.614.565
• Online since: September 2014
• Authors: Wei Liu*, Yan Ping He, Jia Qi Cao, Si Tong Liu, Ying Ying Chen
• Keywords: Differential Thread, Drawing Device, Drawing Die, Mechanical Repairing

References

[1] W. Liu, Y. Shen and C. Lu: Differential Thread Principle's Application in Manual Drawing Device, Applied Mechanics and Materials Vol. 385-386 (2013), p.329.

DOI: 10.4028/www.scientific.net/amm.385-386.329

[2] G. F Ruan: A Kind of Drawing Device, Baogang Technology Vol. 6 (2007), p.25.

[3] W.S. Fang, Y.Z. Zhao and J. Zhang: The Application of Homemade Coupling and Drawing Device, Mine Machinery Vol. 6 (2009), p.61.

[4] C.Y. Liu and Y.L. Liu: Drawing Device Used to Remove the Components of Roller, Mechanical Engineering & Maintenance Vol. 7 (2012), p.124.

[5] W. Liu etc. : Analysis of the Improvement of the Drawing Die in Drawing Device, Applied Mechanics and Materials Vol. 496-500 (2014), p.1041.

DOI: 10.4028/www.scientific.net/amm.496-500.1041
