Research on the Connection Type between Evaporating Tube Bundle and a Steam Drum Shell on a Natural Circulation Marine Supercharged Boiler

Abstract:

The research work, Ascertaining the connection type between evaporating tube bundle and a steam drum shell on a Natural Circulation marine supercharged boiler, is important. For this reason the method, calculating the low-cyle fatigue life of supercharged boiler steam drums put forward by Xin-wei Zheng, et al., was put to use; Based on the relevant basic data from design department and two typical running conditions of one supercharged boiler, the cumulative fatigue damage ratio of welding technique was calculated. The calculated result proves that it exceeds the maximum value of 1.0 and the upper limit value of 0.75 in fossil-fuel power plants, respectively. So welding technique can’t guarantee the low-cycle fatigue life of this steam drum, the only connection type is expanded joint, and the connection type has been put into practice.

• Periodical: Applied Mechanics and Materials (Volume 618)
• Pages: 448-452
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.618.448
• Online since: August 2014
• Authors: Xin Wei Zheng*, Xue Cong Hu, Zhi Yu Wang, An Li Miao
• Keywords: Connection Type, Evaporating Tube Bundle, Low-Cycle Fatigue Life, Marine Supercharged Boiler, Steam Drum Shell

References

[1] Xin-wei Zheng, Yu Sun, and Xiao-jun Wang: Journal of Engineering for Thermal and Power, Issue 2, Vol. 25 (2010), pp.184-189.

[2] Xin-wei Zheng, Zheng Li, and Hao Wang: Advanced Materials Research, Vol. 383-390 (2012), pp.5496-5503.

[3] Xin-wei Zheng, Zhi-yu Wang, and Zi-gang Chen: Advanced Materials Research, Vol. 383-390 (2012), pp.6383-6390.

[4] GB/T9222, Normative Appendix A of Strength Calculation of Pressure Parts for Water-tube Boilers, China Standards Publishing House, Beijing, China, (2008).

[5] Xin-wei Zheng, Zheng Li, and Xiu-hui Chen: Advanced Materials Research, Vol. 383-390 (2012), pp.7682-7690.

[6] Xin-wei Zheng, Wen-ping Zhang, and Peng Zhang, Proceedings of 2012 International Conference on Maritime Technology, Harbin Engineering University Press, Harbin, China, 2012, pp.471-476.

[7] Xin-wei Zheng, Dong-yang Zhang, and Bing Han, Advances in Intelligent and Soft Computing, Vol. 119 (2011), pp.723-734.

[8] Shanghai Power Equipment Research Institute, Specification for Fabrication of Boiler Durms, Shanghai Power Equipment Research Institute, Shanghai, China, 1998, pp.23-33.

[9] CVDA, Code of Assessment for Pressure Vessels, China Boiler and vessel Safety Publishing House, Beijing, China, (1984).

[10] GB/T19624, Safety Assessment for In-service Pressure Vessels Containing Defects, China Standards Publishing House, Beijing, China, (2004).

[11] Shi-rui Tai, Jun Wang, and Shou-zhi Yu, Marine Boilers, National Defence Industry Press, Beijing, China, 1984, p.311.

[12] Zhi-guang Li, Application manual on the strength calculating standards of boilers, China Standards Publishing House, Beijing, China, 2008, p.49.

[13] China Power Engineering Academy, Vol. 1 of Technical Manual of Power Generation Equipments, China Machine Publishing House, Bijing, China, 2008, pp.18-38.

[14] DL/T654, The Technical Guide for the Life Assessment of Units in Fossil-fuel Power Plant, China Electric Power Publishing House, Beijing, China, 2009, p.11.
