Power Quality Problems in PV Fed Grid Connected Inverter

Abstract:

—– In this paper, problem faced by grid connected pv inverter is presented. Inverters connected to grid are mostly affected due to short circuit problems in the power systems. Therefore it is essential to analyze power quality disturbances in order to improve the quality of the system. Performance of inverter is affected severely by voltage sag compared to other type of power quality disturbances. Also in this paper, multilevel inverter with sag condition and without sag condition is simulated using MATLAB/SIMULINK software

• Periodical: Applied Mechanics and Materials (Volume 622)
• Pages: 147-151
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.622.147
• Online since: August 2014
• Authors: Natesan Saritha*, Venkatesan Jamuna, NANTHINI N
• Keywords: Grid Connected Inverter, Modified h Bridge, Multilevel Inverter (MLI), Photovoltaic (PV) System, Power Quality, Pulse Width Modulation (PWM), Total Harmonic Distortion (THD), Voltage Sag

References

[1] .Chakravarthy P.C, Daivaasirvadam.M 'A Hybrid Cascaded Seven-Level Inverter with Novel Pulse Width Modulation Technique For PV Applications' IJERA vol. 2, Issue 6, pp.1660-1665,2012.

[2] Kumar chinnaiyan.V, Dr.Jovitha Jerome 'Control Techniques for Multilevel voltage source inverters' IPEC, 8thInternational power engineering conference,vol.5,pp.978-981,2007.

[3] Mahrous Ahmed, Mahmoud A. Sayed 'Single-Phase Five-Level Inverter with Less Number of Power Elements for Grid Connection' IEEE Trans. vol.6 pp.1521-1527,2012.

DOI: 10.1109/apec.2012.6166022

[4] Mohseni, Islam S.M, and Masoum M.A.S 'Impacts of symmetrical and asymmetrical voltage sags on DFIG-based wind turbines considering phase-angle jump, voltage recovery, and sag parameters," IEEE Trans. Power Electron, vol. 26, no. 5, p.1587–1598,2011.

DOI: 10.1109/tpel.2010.2087771

[5] Nasrudin A. Rahim, Senior Member, IEEE, Krismadinata Chaniag ,student member, IEEE, and Jeyraj Selvaraj 'Single-Phase Seven-Level Grid-Connected Inverter for Photovoltaic System',IEEE Trans. Power Electron, vol.58, no. 6,2003.

DOI: 10.1109/tie.2010.2064278

[6] Radan and Shahirinia .L 'Implementation and Control of distributed PWM cascaded multilevel inverters with minimal harmonic distortion and common –mode voltage', IEEE Trans.Power Electron.,vol.20, no.1, pp.90-99, 2003.

DOI: 10.1109/tpel.2004.839830

[7] Soeren Baekhoej Kjaer, Member, John K. Pedersen, Senior Member ,IEEE,'A review of Single-Phase Grid-Connected Inverters for Photovoltaic Modules', IEEE Trans.on industry applications, vol. 41, no. 5.pp.0093-9994, 2005.

DOI: 10.1109/tia.2005.853371

[8] Yongheng Yang and Frede Blaabjerg'Low-Voltage Ride-Through Capability of a Single-Stage Single-Phase Photovoltaic System Connected to the Low-Voltage Grid', InternationalJournalof Photoenergy,vol.13,Article ID 257487,2013.

DOI: 10.1155/2013/257487

[9] Vibhor Chauhan1 Rishi Pratap Singh1 and Seema Dhariwal 'Analysis of Fault Current Limiter (FCL) for Voltage Sag Mitigation through MATLAB/SIMULINK' Jan 2012, pp.50-58, 2012.

[10] K N S Durga Prakash Ch Narendra Kumar' Grid Connected Thirteen Level Inverter for PV System Using PI ControllerInternational Journal of Engineering Research & Technology (IJERT)Vol. 1 Issue 5, July – 2012.
