Analysis on Kinematic Characteristics Relevant to Three-R Bar Group

Abstract:

Three R bar group as a typical mechanism of a linkage is studied. Analysis method is based on the theory of kinematics and the method of mathematics. After deriving of relevant kinematic equations, detail analysis about positions, velocities, accelerations, and angles, angular velocities, angular accelerations of bars as well as other kinematics parameters of three R bar group to be searched can be obtained in the paper. Relationships between known and unknown parameters of three R bar group have been determined according to different working states of three R bar group. The method presented in the paper provides a feasible and more efficient method for the analysis of kinematic characteristics of plane linkages.

• Periodical: Applied Mechanics and Materials (Volumes 63-64)
• Pages: 115-118
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.63-64.115
• Online since: June 2011
• Authors: Lin Hong
• Keywords: Bar Group, Kinematics Analysis, Linkage Mechanism, Parameter Design

References

[1] Guo Xiaoning. Research on Structural and Kinematic Characteristics and Parameterized Solid Kinematic Simulation of Linkages [D], Xian University of Technology, Xian, (2003).

[2] YAO Rui, TANG Xiaoqiang, HUANG Peng. Dimensional design of flexible 3-RRR planar parallel manipulator with high acceleration [J]. Journal of Tsinghua University (Science and Technology), 2008, 48(2): 184-188. in Chinese.

[3] CHI Jian-bin, LI Wei-min, FENG Gui-zhen. Modeling and Simulation of Innovation Design of Linkage Mechanism. Journal of Engineering Graphics, 2010, 31(5): 89-95, in Chinese.
