Agricultural Robot Turning in the Headland of Corn Fields

Abstract:

This article discusses the development of variable field of view (FOV) of camera to realize headland turning of an agricultural robot in corn fields. The variable FOV of camera was implemented to change direction of view of camera by two DC motors rotating separately in vertical and horizontal planes. Headland turning is executed in six steps: end of row detection and guidance, going blind for a distance, first 90˚ turning, position calculation, backing control, second 90˚ turning. Mathematically morphological operations were chosen to segment crops, and fuzzy logic control was applied to guide the robot. Three repetition tests were conducted to perform the headland turning. A maximum error of 17.4mm when using the lateral view and good headland turning operation were observed. It was successful for variable FOV to implement headland turning of the agricultural robot in corn fields.

• Periodical: Applied Mechanics and Materials (Volumes 63-64)
• Pages: 780-784
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.63-64.780
• Online since: June 2011
• Authors: Jin Lin Xue, Tony E. Grift
• Keywords: Agricultural Robot, Field of View, Machine Vision, Turning

References

[1] T. Torii, T. Teshima, T. Okamoto, K. Imou, Y. Kaizu, K. Taniwaki and Y. Nagasaka: Vision Based Navigation of a Boom Sprayer, Journal of JSAM, Vol. 65 (2003), pp.70-75

[2] N.D. Tillett, T. Hague and S.J. Miles: Inter-row Vision Guidance for Mechanical Weed Control in Sugar Beet, Computer and Electronics in Agriculture, Vol. 33(2002), pp.163-177

DOI: 10.1016/s0168-1699(02)00005-4

[3] B. Åstrand and A.-J. Baerveldt: A Vision Based Row-following System for Agricultural Field Machinery, Mechatronics, Vol. 15(2005), pp.251-269.

DOI: 10.1016/j.mechatronics.2004.05.005

[4] E.R. Benson, J.F. Reid and Q. Zhang: Machine Vision-based Guidance System for Agricultural Grain Harvesters Using Cut-edge Detection, Biosystems Engineering, Vol. 86(2003), pp.389-398

DOI: 10.1016/j.biosystemseng.2003.07.002

[5] B. Chen, S. Tojo, and K. Watanabe: Machine Vision for a Micro Weeding Robot in a Paddy Field, Biosystems Engineering, Vol. 85(2003), pp.393-404

DOI: 10.1016/s1537-5110(03)00078-3

[6] T. Bak and H. Jakobsen: Agricultural Robotic Platform with Four Wheel Steering for Weed Detection, Biosystems Engineering, Vol. 87(2004), pp.125-136

DOI: 10.1016/j.biosystemseng.2003.10.009

[7] J.L. Xue and L.M. Xu, Autonomous Agricultural Robot and its Row Guidance. In: 2010 International Conference on Measuring Technology and Mechatronics Automation. Changsha, China: IEEE, pp.725-729

DOI: 10.1109/icmtma.2010.251
