Studying the Interaction of Liquid and Solid in the Flow of Liquid in Annulus by CFD Analysis

Abstract:

This article is aimed to define the flow in the annulus. The shaft is deposited in a case which has at inlet and outlet recess. The rotor moves in the case. This movement can be divided into the rotation and precession. It is situation where the rotor rotates around own axis and together moves along the circle. The solution of the problem was the initiative in practice where this type of movement occurs in many components, e.g. sliding journal bearings. The fluid flows in the annulus due to the pressure gradient between inlet and outlet and together takes place rotational movement due to movement of the rotor. Between the liquid and the solid of an interaction which results in a change in the forces. The problem is solved by mathematical CFD solver ANSYS Fluent. Based on the characteristics of the problem has been defined corresponding to a mathematical model for the selected types of liquids - VG 32 mineral oil, VG 150 mineral oil and water. Individual variants of used liquids are compared with each other courses of forces acting on the rotor under the same boundary conditions.

• Periodical: Applied Mechanics and Materials (Volume 630)
• Pages: 220-227
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.630.220
• Online since: September 2014
• Authors: Michal Kozdera, Marian Bojko*, Sylva Drábková, Milada Kozubková
• Keywords: Annulus, ANSYS FLUENT, CFD Modeling, Fluid Flow, Liquid

References

[1] B.H. Rho, K.W. Kim, Acoustic properties of hydrodynamic journal bearing, Trib. Int. 36 (2003) 61-66.

[2] J. Sep, Three-dimensional hydrodynamic analysis of a journal bearing with a two-component surface layer, Trib. Int. 38 (2005) 97-104.

DOI: 10.1016/j.triboint.2004.02.004

[3] C.W. Wu, G.J. Ma, Abnormal behavior of a hydrodynamic lubrication journal bearing caused by wall slip, Trib. Int. 38 (2005) 492-499.

DOI: 10.1016/j.triboint.2004.10.004

[4] J. Frêne, M. Arghir, V. Constantinescu, Combined thin-film and Navier-Stokes analysis in high Reynolds number lubrication, Trib. Int. 39 (2006) 734-747.

DOI: 10.1016/j.triboint.2005.07.004

[5] C.W. Chang-Jian, C.K. Chen, Bifurcation analysis of flexible rotor supported by couple-stress fluid film bearing with non-linear suspension systems, Trib. Int. 41 (2008) 367-386.

DOI: 10.1016/j.triboint.2007.09.007

[6] K.P. Gertzos, P.G. Nikolakopoulos, C.A. Papadopoulos, CFD analysis of journal bearing hydrodynamic lubrication by Bingham lubricant.

DOI: 10.1016/j.triboint.2008.03.002

[7] F. Pochylý, S. Fialová, M. Kozubková, M. Bojko, Tensors of added damping, stiffness and mass in a thin gap of hydrodynamic machine, Earth and Environ. Science. 15 (2012).

DOI: 10.1088/1755-1315/15/7/072027

[8] M. Bojko, M. Kozdera, M. Kozubková, Investigation of viscous fluid flow in an eccentrically deposited annulus using CFD methods, EPJ 45 (2011).

DOI: 10.1051/epjconf/20134501115

[9] M. Bojko, M. Kozubková, M. Kozdera, O. Zavila, Investigation of the influence of radial grooves on the flow in an eccentrically deposited annulus using CFD numerical methods, EPJ 67 (2014).

DOI: 10.1051/epjconf/20146702009

[10] ANSYS Fluent 14 - User´s Guide. Fluent Inc, (2011).
