Research on the Field Dynamic Balancing Technology and Instrument for a High Speed Cantilever Rotor

Abstract:

The principle of balancing a high speed cantilever rotor at full speed has been put forward by low-speed and high-speed balancing. The portable field dynamic balancing instrument based on the microcontroller is discussed from the hardware, the software and the signal process in detail. With the developed instrument, the whole-machine balancing experiment was conducted on a saucer-separating centrifuge RJ-460. The vibration of the saucer-separating centrifuge decreased from 3.8mm/s to 0.3mm/s at 1200r/min and decreased from 9.8mm/s to 0.6mm/s at 7200r/min. The experimental results indicated that the principle of balance is correct and the designed instrument is reliable and promising.

• Periodical: Applied Mechanics and Materials (Volumes 633-634)
• Pages: 1220-1228
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.633-634.1220
• Online since: September 2014
• Authors: Zhi Xin Zhang, Yu Long Fu*, Shi Zheng He, Ji Yong Kuang
• Keywords: Dynamic Balancing, Instrument, Saucer-Separating Centrifuge, Signal Process

References

[1] S.Z. He, S.X. Chen, The Analysis of Unbalance Reasons for Assemble Drum of Saucer-separating Centrifuge[J], Fluid Engineering, 1993, 21(10).: 36-39. (In Chinese).

[2] X.J. Ma, The Analysis and Diagnosis of Dish Centrifugal Separator's Main Faults, Ph.D. Thesis, Zhejiang University, 2000. (In Chinese).

[3] R. Keith Mobley, Maintenance Fundamentals (Second Edition), 2004, Pages 112-124.

[4] B.T. Zhou, Vibration test and dynamic balance, Zhejiang University Press, Hangzhou, 1991. (In Chinese).

[5] Sperling L, Ryzhik B, Linz Ch, et al. Simulation of two-plane automatic balancing of a rigid rotor, Mathematics and Computers in Simulation. 2002, 58: 351-365.

DOI: 10.1016/s0378-4754(01)00377-9

[6] Zhou S, Shi J. Optimal one-plane active balancing of a rigid rotor during acceleration, Journal of Sound and Vibration. 2002, 249: 196-205.

DOI: 10.1006/jsvi.2001.3660

[7] Xu B, Qu L, Sun R. The optimization technique-based balancing of flexible rotors without test run, Journal of Sound and Vibration. 2000, 238: 877-892.

DOI: 10.1006/jsvi.2000.3107

[8] A.L. Morales, A.J. Nieto, J.M. Chicharro, P. Pintado, Vibration isolation of unbalanced machinery using an adaptive-passive magnetoelastic suspension, Journal of Sound and Vibration, Volume 331, Issue 2, 12 January 2012, Pages 263-275.

DOI: 10.1016/j.jsv.2011.09.003

[9] Y.H. Zhong, Y.Z. He, Z. Wang, F.Z. Li, Rotor dynamics, Tsinghua University Press, Beijin, 1987. (In Chinese).

[10] L.M. He, The Design Configuration and Interface Technology of MCS-51 Series PLC System [M], Beihang University Press, Beijing, 1994. (In Chinese).

[11] Z.X. Zhang, Development and research of the intelligent whole-machine balancing instrument for dual-rotor system with little rotating speed difference, Ph.D. Thesis, Zhejiang University, 2001. (In Chinese).
