Simulation Analysis on Dynamic Characteristics of a Quad Intergrated Mirror Frame

Abstract:

The “SG” is a large inertial confinement fusion (ICF) project that is building in china. Its essential working principium is stimulating the nuclear material in the target ball by shooting with laser, then the ICF will produce large numbers of fusion energy which is controllable. The laser is lead and transmited primary by mirror which is clamped by mirror frame in the shooting range system.For the needs of precision when shooting, there are some strict demands to the dynamic characteristics of the mirror frame. This paper designed a machine model of a array mirror frame which is quad intergrated, and simulation analysis on dynamic characteristics of the mirror frame .

• Periodical: Applied Mechanics and Materials (Volumes 633-634)
• Pages: 1229-1232
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.633-634.1229
• Online since: September 2014
• Authors: Guang Zhao, Chun Xiang Pan, Yan Wang
• Keywords: Dynamic Characteristic, Inertial Confinement Fusion, Modal, Resonance

References

[1] S. I. Fedotov, L. P. Feoktistov. Lasers for ICF with a Controllable Function of Mutual Coherence of Radiation. Russian Laser Research. Vol. 79-92(2004) , p.435.

DOI: 10.1023/b:jorr.0000012486.89881.d8

[2] Hou Guoan. Research of Orthogonal Axial Electric Mirror Holder for Large CaliberLaser . Harbin Institute of Technology master's thesis. 10-13. (2008).

[3] Dong Jihong. Ball Hinge Support Design and Analysis for Large Aperture Optical Mirror . OME information. Vol. 27(9) (2010) , pp.29-33.

[4] Zhu Maoxiang. Frame structure research and manufacturing of a new type array mirror for ICF drive system . High Power Laser Particals Beams. Vol. 14(6) (2002) , pp.862-864.

[5] Wu Qingwen, Lu E and Wang Jiaqi. Study on the Surface Figure Changes or primary Mirror Centerally Supported Under Gravity Load . OPTICS AND PRECISION ENGINEERING. Vol. 4(4) (1996) pp.23-27.
