The Finite Element Analysis of Lei-Ring Applied to Upright Column for Hydraulic Support

Abstract:

Abstract:In this paper ,the finite element model of the lei-ring was established in ANSYS software,the sealing performance of hydraulic support column piston was analyzed.Also,the numerical simulation analysis was made of the impact of column working pressure on the sealing performance,and a series of the integrated equivalent stress and contact pressure images of sealing ring when working were got. From those images,the location most prone to failure can be concluded.All of work can provide a theoretical reference for the design and use of drum sealing ring used on hydraulic support upright column.

• Periodical: Applied Mechanics and Materials (Volumes 635-637)
• Pages: 541-544
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.635-637.541
• Online since: September 2014
• Authors: Hai Ning Li, Dan Li*, Xin Xin
• Keywords: Contact Pressure, Lei-Ring, Sealing Performance, Upright Column

References

[1] Zhou Entao，Li Jianxun，Lin Junzhe．Finite element analysis of piston seals property of hydraulic cylinders[J]. Lubrication Engineering, 2006, 31(4): 84-85.

[2] Hu Dianyin, Wang Rongqiao, Ren Quanbinetal Finite element analysis of O-ring seal structure [J]. Journal of Beijing University of Aeronautics and Astronautics, 2005, 31(2) : 255-260.

[3] Chen Biao, Zhang Zanlao, Yang Jianyong, et al. Finite element analysis on rubber sealing Y-ring in the condition of static seal[J]. Lubrication Engineering, 2009, 34(3): 72-75.

[4] Zheng Ming jun, Xie Jilong. Finite Element Analysis of Large Deformation of Compressed Rubber Component [J]. Journal of Northern Jiao tong University, 2001, 25(1): 76-79.

[5] Wang Shiqiang Zhang Fuying Zhang Dongge. Study on Sealing Performance of Y-ring Based on ANSYS[J]. Lubrication Engineering, 2012, 37(12): 61-64.

[6] Wang Jie, Xie Yujun. Ansys Analysis of Rubber O- Sealing Ring [J]. Journal of Liaoning University of Petroleum &Chemical Technology, 2008, 28(4): 48- 57.

[7] Zhang Zhenxiu, Nie Jun, Shen Mei, et al. Super elasticity model in ANASYS and its application in rubber engineering［J］China Rubber /Plastics Technology and Equipment, 2005, 31(9): 1- 5.
