3-D NC Testing Platform Based on Motion Control Card

Abstract:

Researched the virtual-actual integrated technology based on the computer simulation test, 3-D NC test platform was mentioned using ′PC+Motion controller′as the core. In the VC++6.0 environment, the MFC series and the GT motion controller dynamic link library was used to realize multi axis linkage control function and 3-D NC control system software was developed. The “” vector control strategy and the SimPowerSystem module library was used to establish the system simulation of PMSM vector control model, Matlab software and InTouch software were used to realize the virtual simulation and associated debugging for control system and mechanical transmission system, the feasibility of numerical control testing platform was verified .

• Periodical: Applied Mechanics and Materials (Volumes 635-637)
• Pages: 639-642
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.635-637.639
• Online since: September 2014
• Authors: Hong Mei Yin*, Mu Lan Wang, Chang Ye
• Keywords: Motion Control Card, NC Testing Platform, Software Development, Virtual Reality Integrated Technology, Virtual Simulation
