Impact of Track Longitudinal Resistance on the Calculation of Continuous Welded Rail Sited on the Bridge

Abstract:

In order to find the impact on longitudinal resistance of continuously welded rails on bridge under different longitudinal resistance of the lines, based on the principle of the interaction between bridge and track, an integrative rail-bridge-pier calculation model of CWR on bridge is developed. Take simple-supported and continuous beam bridge as example to analyze the influence of continuously welded rails on bridge under different line resistance. The result shows that whether simple-supported or continuous beam bridge, the additional expansion forces which conducted by the constant resistance are smaller than the bilinear and power-exponential resistance, and the gap becomes greater as the increasing of the expansion length, and the calculation of the bilinear and power-exponential resistance becomes more and more similar. Besides, the calculation of the braking forces which conducted by the constant resistance is smaller than the bilinear and power-exponential resistance, while the displacement between the rail and beams is bigger, and has exceeded the calculation standard; the breaking joint of rail conducted under different longitudinal resistance is basically the same, but decreased gradually with the maximum line resistance increased.

• Periodical: Applied Mechanics and Materials (Volumes 638-640)
• Pages: 947-953
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.638-640.947
• Online since: September 2014
• Authors: Liu Hao*, Qi Wei, Ping Wang, Jie Ling Xiao
• Keywords: Continuously Welded Rail on Bridge, Expansion Length, Interact Role between Bridge and Rail, Line Resistance

References

[1] Yanli Yang. Experimental Study on Design Parameters of Longitudinal and Lateral Resistance of Ballast Bed for III-Type Concrete Sleeper[J]. Journal of Railway Engineering Society, ( 2014) No. 10, P49-51. (In Chinese).

[2] Qingyuan XU, Xiaolin ZHOU. Computation model of additional longitudinal forces of continuously welded rails on bridges[J]. Journal of Traffic and Transportation Engineering, (2004) No. 1, P25-28. (In Chinese).

[3] Xinmin Wang. ANSYS Numerical Analysis of Engineering Structure[M]. People's Traffic Press, (2007).

[4] Xiankui Wei. Development and application of software of calculating CWR on bridge[J]. Railway Engineering, (2010). No. 8, P115-118. (In Chinese).

[5] China Railway Siyuan Survey And Design Group Co. LTD, Design specifications of CWR[S], China railway publishing house, 2007. (In Chinese).
