Research on the Control System of the Lower Limb Rehabilitation Robot under the Single Degree of Freedom

Abstract:

This paper studies the PID control algorithm of foot-pedal lower limb rehabilitation robot which can be viewed as a single closed-loop DC speed regulating system. It is necessary to ensure the steady state of the system under various types of interference and the setting of PID parameters will take a lot of time and energy. For this reason, GA (Genetic Algorithms) is used to set the PID parameters in this paper, PID parameters optimized by different goal functions are presented. The simulation results show that the GA simplifies the setting of PID parameters, for different goal functions make the system outputs have different characteristics.

• Periodical: Applied Mechanics and Materials (Volume 643)
• Pages: 15-20
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.643.15
• Online since: September 2014
• Authors: Ming Xiong*
• Keywords: GA, Goal Function, Rehabilitation Robot, Single Close-Loop DC Speed Regulating System

References

[1] Xu Guozheng, Song Aiguo, Li Huijun. The architecture and control technology of rehabilitation robot system[J]. Chinese Journal of Tissue Engineering Research, 2009, 13 (4) : 717-720.

[2] Chen Boshi. Electric drive automatic control system - motion control system [M] Beijing: Mechanical Industry Press . 2004: 32-33.

[3] Hu Shousong. Automatic control theory (6th Edition) [M] Beijing: Science Press . 2013: 99-101.

[4] Liu Hehua, Cui Chao, Chen Jing. Research on the traveling salesman based on an improved genetic algorithm [J]. Beijing University of Technology, 2013, 33 (4) : 390-393.

[5] Liu Jinkun. MATLAB simulation based on the advanced PID control (3rd Edition) [M] Beijing: Electronic Industry Press, 2011: 210-211.

[6] Zhang Lixun, Li Changsheng, Liu Fuqiang. Design of the multi-mode lower limb rehabilitation robot and its experimental analysis[J]. Chinese Journal of Rehabilitation Medicine . 2011, 26 (5) : 464-466.

[7] Xu Guozheng, Song Aiguo, Li Huijun. On the impedance control of the upper limb rehabilitation robot based on fuzzy logic [J] control. Robot . 2010, 32 (6) : 792-797.

[8] Liang Chunying, Lu Peng, Ji Jianwei, Wang Xi. PID parameter optimization of the electro-hydraulic variable fertilization control system based on genetic algorithms [J]. Journal of Agricultural Machinery . 2013, 44 (S1) : 89-93.

[9] Gao Yuan Hai, Wang Chun. On the non-revisiting genetic algorithm and its application in transmission network planning [J]. Proceedings of the CSEE . 2013, 33 (4) : 110-117.
