Two Degrees of Freedom Manipulator Kinematics Analysis and Simulation

Abstract:

A 2-DOF manipulator is modeled in PROE. In MATLAB, inverse kinematics is solved by geometric method. The desired trajectory, angular velocity and angular acceleration of each joint are obtained by the linear interpolation of parabola transition to complete the kinematics planning of the manipulator. The velocity of the end-point and the kinematics analysis are got by Newton-Euler method. In PROE, the expected trajectory of the end point is got by the simulation of the position planning. Kinematics simulation on the model is made in ADAMS. The simulation results are consistent with theoretical calculations to verify the correctness of the theory computing, which can provide an effective basis for the control of the manipulator.

• Periodical: Applied Mechanics and Materials (Volumes 644-650)
• Pages: 112-116
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.644-650.112
• Online since: September 2014
• Authors: Lu Wei Guan*, Cai Wen Ma, Jun Feng Han
• Keywords: Kinematics, Manipulator, Simulation

References

[1] S. Bulut and M.B. Terzioglu: Joint angle variations analyses of the two link planar manipulator in welding by using inverse kinematics, 12: 355-363, (2006).

DOI: 10.1017/s0263574705002274

[2] Min Tan, De Xu and Zengguang Hou, in: Advanced robot control, Bei Jing (2007), in press.

[3] Qizhi Zhang: The robot introductory tutorial, Xi'an(2013).

[4] Zixing Cai: Robotics, Bei Jing(2007).

[5] Aicheng Li. et al: The kinematics analysis and dynamic simulation of joint type palletizing robot, Mechanical design, (2013).
