Study on Wireless Weighing System

Abstract:

In order to achieve the wireless operation of the data collected and system monitoring in the weighing equipment, a wireless weighing system design was proposed. This scheme combines with the weighing control technology and the wireless communications technology. The weighing system includes the pressure sensor, the signal processing module, the microprocessors, wireless data transceiver module, the infrared module, the memory module, the display module and the control module. Based on the experiment of ten different targets ranged from 5kg to 50kg, the wireless weighing system was measured and analyzed. Experimental results show that the maximum error rate of the wireless weighing system is 0.2%, and wireless transmission distance reaches two hundred meters.
