Design of Test Bench for Flyweel of the Shaft-Seal Nuclear Coolant Pump and ANSYS Analysis

Abstract:

Due to the test requirements of flyweel of the shaft-seal nuclear coolant pump, design the structure of the test bench.Based on the theory of finite element analysis,use ANSYS software carries on its ststic analysis to gain the displacement and the stress form in order to check the strength and stiffness,and then carries on modal analysis to get its first six natural frequency and vibration in order to verify the rationality of design.CLC :TH122

• Periodical: Applied Mechanics and Materials (Volumes 644-650)
• Pages: 559-562
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.644-650.559
• Online since: September 2014
• Authors: Sheng Song Wang*, Ping Hu, Hai Ni Yao
• Keywords: Modal Analysis, Static Analysis, Test Bench
