Research on Wind Power Compensation Ratio of Vanadium Flow Battery Based on Power Optimization

Abstract:

Because of the high spending and better smoothing affect of VRB, studying the wind power compensation ratio of VRB system become more and more important. The paper proposes a new way to get the power compensation ratio of VRB system, through analyzing the transient stability influence on wind speed fluctuation. Make use of PSASP for transient stability analyzing and observe the smooth affect of the wind disturbance based on the model of IEEE-14. The performance of the proposed method has been evaluated with the comparison of transient stability analyze, the comparison demonstrates the wind power compensation ratio of VRB system.

• Periodical: Applied Mechanics and Materials (Volumes 651-653)
• Pages: 1088-1092
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.651-653.1088
• Online since: September 2014
• Authors: Xiang Ming Wang*, Jing Meng, Kun Bin
• Keywords: Power Compensation Ratio, Transient Stability, VRB, Wind Power

References

[1] Liu Deshun, Dai Juchuan, and Hu Yanping, in: Present situation and the development trend of modern large-scale wind turbines, edited by China Mechanical Engineering, vol. 25-134, 135(2013).

[2] TIAN Chunzheng, LI Qionglin and Song Xiaokai in: Modeling and analysis of the stability for the power system considering the integration of the wind farms. Published by Power System Protection and Control, vol. 46-51(2009).

[3] Zhang Wenliang, Qiu Ming and Lai Xiaokang, in: Application of energy storage technologies in power system. Published Power System Technology, Vol. 1-9(2008).

[4] Billinton R B. Reliability considerations in the utilization of wind energy, solar energy and energy storage in electric power systems. International Conference on Probabilistic Methods Applied to Power Systems, Stockholm, vol. 1-6(2006).

DOI: 10.1109/pmaps.2006.360204

[5] Pang Aili. The influence of the system access to wind farm . Shanghai Electric Power, vol. 33—35(2007).

[6] Wang Xiangming, Gao Yang, Liu Lijun. Research on capacity of wind farm maximum power integration[J]. Acta Energiae Solaris Sinica, vol. 1510—1515(2012).

[7] Sun Tao, Chen Z, Frede Blaabkerg. Transient analysis of grid-connected wind turbines with DFIG after an external short circuit fault. Nordic Wind Power Conference Gothenburg(2004).

DOI: 10.1109/pesc.2004.1355423

[8] Tomilson A, Quaicoe J, GosineR, etal. Modeling an autonomous wind-diesel system on Simulink. Electrical and Computer Enegineering, vol. 35—38(1997).

[9] Mao Meiqin. Research on wind-solar-diesel-battery hybrid power generation and intelligent control system. Hefei: Hefei University of technology(2004).

[10] Wang Xiangming, Li Qilei and Guo Yumei. Research on VRB modeling based on Matlab/Simulink. Chinese Journal of Power Sources, vol. 234—237(2013).
