Simulation Realization of LV SVG Control Algorithm Based on EMTDC and C Language Mixed Programming

Abstract:

EMTDC is grid simulation analysis software that is capable of modeling for complex electrical and electronic devices, controllers and non-linear network. PSCAD is a user graphical interface of EMTDC. In PSCAD environment, functional modules can be taken from the element library conveniently to set up a complete set of LV SVG control system for simulation study of operation performances under various work conditions. However, the control program of LV SVG in actual application is written in C language, which has great differences from some functional modules in PSCAD simulation module in terms of data processing approach and calculation precision, so there is a huge gap from the simulation result and the actual result.In this paper, Fortran language is used to write interface function. Control program written in C language is embedded into the simulation module set up by EMTDC. An experiment shows that the simulation model built by EMTDC and C language mixed programming has higher precision than ordinary simulation module, and can be transplanted among LV SVG controllers, so it’s more practical.

• Periodical: Applied Mechanics and Materials (Volumes 651-653)
• Pages: 1093-1096
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.651-653.1093
• Online since: September 2014
• Authors: Yu Jie Pei*, Jing Long Mu, Lei Zhang, Xian Feng Li, Min Jin, Shu Han Wang, Jia Yong Chen
• Keywords: C Language Mixed Programming, EMTDC, LV SVG
