Design of Control System for Hydraulically Vibrated Processing Tomato Fruit Seedling Separation Device

Abstract:

Eccentric style processing tomato fruit seeding separation device exist high machining and assembly precision or other issues. In order to solve this problem, the mode of vibration of hydraulic replaced the eccentric style to drive the fruit seedling separation roller to separate processing tomato effectively. To facilitate adjustment of the hydraulic system, a kind of control circuit PLC as the core was designed according to the actual production requirements. PLC and other elements were selected. The system control signal frequency was initially set up as 1~5 HZ, within the frequency range hydraulic simulation software was used to simulate and analyze the hydraulic vibration system. The result shows that the system rams steady when the input signal frequency range was 1~5HZ.

• Periodical: Applied Mechanics and Materials (Volumes 651-653)
• Pages: 693-696
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.651-653.693
• Online since: September 2014
• Authors: Li Hong Wang*, Rong Qing Liang, Cheng Song Li, Za Kan, Jin Wei Qin
• Keywords: Fruit Seedling Separation Devices, Hydraulic Vibration, PLC, Processing Tomato

References

[1] ZHANG J, REN W.X. Analysis of prospects for the development of the tomato harvest mechanization [J]. Xinjiang State Farms Economy, 2001(3).

[2] Processing tomato fruit seedling separation device on http: /www. tiaozhanbei. net/project/17238.

[3] LI C. S, LIANG R. Q, KAN Z. The application of hydraulic vibration on tomato fruit separation device [J]. Journal of Agricultural Mechanization Research, 2013(12): 223-236.

[4] LI C. S, QU J. L, KAN Z. The simulation analysis of the processing tomato fruit-plant separation hydraulic vibratory system [J]. Journal of Shihezi University (Natural Science), 2013(6): 775-781.

[5] Yang Y. Research on comprehensive hydraulic test bed with global function based on PLC control [D]. Shenyang: Shenyang university of Technology, 2012.

[6] CHEN D. F, KAN Z, LI C. S, et al. Design of power and start system for self-propelled tomato harvester [J]. Journal of Agricultural Mechanization Research, 2013, 35(04): 67- 71.
