Measuring the Impact Forces within the Cleaning Nozzles Sewage System

Abstract:

Industrial cleaning is a classic application of water jets technology. In the late 1950s, when reliable high pressure pumps were built, the usage of water jets spread widely in the field of pipes and sewerage cleaning. In our particular case, water jets with less than 340 bar pressure are being used. The experiment is the research method used in the study of the impact forces that occur in the sewerage cleaning head system. In order to measure the impact forces between the water jet and a flat and rigid surface, we designed and built a stand for generating pressure jets, as well as a device to measure the impact force. Using the impact forces measured were calculated the coefficients of discharge, speed and contraction of water jet at the outlet of nozzle.

• Periodical: Applied Mechanics and Materials (Volume 657)
• Pages: 564-568
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.657.564
• Online since: October 2014
• Authors: Nicolae Medan*, Sándor Ravai Nagy, Mihai Banica
• Keywords: Impact Force, Low-Pressure Water Cleaning, Nozzle Coefficients, Water Jet

References

[1] W. F. Adler, The Mechanics of Liquid Impact, Treatise on Materials Science and Technology. 16 (1979) 127-183.

[2] S.J. Leach, G.L. Walker, Some Aspects of Rock cutting by High Speed Water Jets, Phil. Trans. Royal Soc. 260 (1966) 295-308.

[3] M.C. Leu, P. Meng, E.S. Geskin, L. Tismeneskiy, Mathematical Modelling and Experimental Verification of Stationary Waterjet Cleaning Process, Journal of Manufacturing Science and Engineering. 120 (1998) 571-579.

DOI: 10.1115/1.2830161

[4] A. Guha, R.M. Barron, R. Balachandar, An Experimental and Numerical Study of Water Jet Cleaning Process, Journal of Materials Processing Tech. 211 (2011) 610-618.

DOI: 10.1016/j.jmatprotec.2010.11.017

[5] Y. Liu, F. Ma, Hui Xie, Y. Li, Development of Impact Test System for Waterjet Descaling Nozzles with LabVIEW, WISM. 1 (2010) 3-7.

DOI: 10.1109/wism.2010.12

[6] M. Annoni, L. Cristaldi, M. Faifer, M. Norgia, Orifice Coefficients Evaluation for Water Jet Application, 16th IMECO TC4 Symposium, Exploring New Frontiers of Instrumentation and Method for Electrical and Electronic Measurement, Florence, Italy, septembrie, (2008).

[7] A. Cotetiu, R. Cotetiu, N. Ungureanu, Research about Automatic Adjustement Solution of the Advance Force at the Perffusion Drills Using Fluid Elements, Archives of Mining Sciences. 58 (2014) 1201-1208.

DOI: 10.2478/amsc-2013-0081

[8] A.W. Momber, Hydroblasting and Coating of Stell Structures, Elsevier Ltd, Oxford, (2003).

[9] N. Medan, Experimental Research Design of the Cleaning Nozzle Sewage System, Research Report, Baia Mare, (2012).
