Research on Optimization of a Chain of Dimensions that Determine the Parallelism between Two Axes

Abstract:

In this paper is presented a statistical method for calculating the establishment of tolerances of a chain of complex dimensions, method which is applied quickly and efficiently by a computer program. The question that arises is the influence of a reducer shaft axis non-parallelism that can lead to some shortcomings in its operation. These deficiencies are based on the size of deviation from parallelism of the axes of the two shafts. For their removal was necessary to study the chain of dimensions which was formed to mount the type of reducer 1400-30/7ERC. Using the data obtained in practice by running a computer program achieved CALTOL was determined statistical tolerance deviation from parallelism between the axis reducer shafts.

• Periodical: Applied Mechanics and Materials (Volume 657)
• Pages: 594-598
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.657.594
• Online since: October 2014
• Authors: Constanţa Rădulescu*, Liviu Marius Cirtina, Liliana Luca
• Keywords: Chain of Dimensions, Optimization, Statistical Method

References

[1] L.M. Cîrţîna, St. Ghimişi and C. Peptan, Influence of the measuring errors over the objectivity process control, TC 15-Youth IMEKO Symposium on Experimental Solid Mechanic, Bertinoro (Forli), Italy, (2002).

[2] L. M. Cîrţînă, L. Luca and St. Ghimişi, Best Designing of a Chain of Dimensions made up when working a Part, 16-th International Conference on Production Research ICPR, Praha, (2001).

[3] S, Backes, Statistical tolerance calculation (in German), Presentation quality managers forum in Munich, Verlag Munich, 1986, pp.279-292.

[4] L.M. Cîrţînă and St. Ghimisi, Influence of the measuring error over the objectivity process control, Proceedings of the International Conference On Naval and Marine Education Romanian Naval Academy's 130th Anniversary, Constanţa, Romania, (2002).

[5] P. F. Dunaev and O.P. Lelikov, Calculation of dimensional tolerances (in Russien), Masinostroienie, Moskva, (1981).

[6] C. Militaru, Reliability and accuracy in machine building, Didactică şi Pedagogică Publishing House, Bucharest, (1987).

[7] Y. R. Pan and G. R. Tang - Computer-Aided Tolerance Charting for Products with Angular Features, International Journal of Advanced Manufacturing Technolgy. (2001) 361–370.

DOI: 10.1007/s001700170171

[8] E. Kreyszig, Statistical methods and their applications (in German), Vandenhoeck and Ruprecht, Gottigen, (1968).

[9] L. M. Cîrţînă and C. Rădulescu, The solving a complex chain of dimensions by the statistic methods, Proceedings of the 8th International Conference on Applied and Theoretical Mechanics, Montreux, Switzerland, (2012).

[10] G. R. Tang, R. Kung and J. Y. Chen, Optimal allocation of process tolerances and stock removals, International Journal of Production Research. 32(1) (1994) 23–35.

DOI: 10.1080/00207549408956913

[11] B. Klein and F. Mannewitz, Statistical tolerance, Quality of the constructive design (in German), Viweg Wisbaded, (1993).
