Impact Analysis of an Oxygen Mask Locking Panel of Aircraft Using Finite Element Modelling

Abstract:

This paper presents a method of finite element modelling used for the impact analysis of a composite panel. In this research, the composite panel consists of an oxygen mask locking panel of an aircraft. This panel is loaded with one concentrated abuse loading and three uniform distributed abuse loading cases and the stress variation within the composite panel for each load case is determined. In order to assess the impact analysis on the oxygen mask panel of the aircraft, a finite element model is created using Patran as the main application for pre/post-processing and Nastran as the main processor. The paper also presents a comparison between results obtained using the same finite element modelling of the composite panel CAD model of the panel with four load cases with different material types. The results are used to determine the most capable material stresswise.

• Periodical: Applied Mechanics and Materials (Volume 657)
• Pages: 735-739
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.657.735
• Online since: October 2014
• Authors: Emilian Ionut Croitoru*, Gheorghe Oancea
• Keywords: Composite Material, Composite Panels, Finite Element Modeling (FEM), Impact Analysis, Mesh, NASTRAN, Oxygen Mask Panel, PATRAN
