Positioning Systems Actuated by Corrugated Tube Elements

Abstract:

The purpose of this paper is to validate the actuation of the positioning systems with a new type of pneumatic actuators based on corrugated tubular elements. The latter are also called bellows, usually operating as sealing elements or as pressure transducers.The CAD models of two positioning systems actuated with corrugated tube elements are given. The first one, with one degree of freedom, is driven by two bellows disposed in antagonist way, powered with different pressures, offering different displacements and adjustable stiffness. The second positioning system contains two overlapping platforms that can slide on two axis, (having two degrees of fredom), their operation being performed individualy with two pairs of bellows arranged in antagonist way, on two levels, disposed at 90⁰ from each other. Pneumatic diagrams for the two positioning systems are given. Experimental prototypes are developed and the results of the first tests are presented.

• Periodical: Applied Mechanics and Materials (Volume 658)
• Pages: 644-647
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.658.644
• Online since: October 2014
• Authors: Vasile Sergiu Jişa*, Beniamin Vasile Chetran, Dan Mândru
• Keywords: Bellows Actuators, Corrugated Tubes, Pneumatics, Translation Stage

References

[1] A. De Greef, P. Lambert, A. Delchambre, Towards flexible medical instruments: Review of flexible fluidic actuators, Precision Engineering 33 (2009) 311–321.

DOI: 10.1016/j.precisioneng.2008.10.004

[2] M.C. Dudescu, Calculul de rezistenta al tuburilor ondulate, U.T. PRES, Cluj – Napoca, (2005).

[3] A. Kargov, T. Werner, C. Pylatiuk, S. Schulz, Development of a miniaturised hydraulic actuation system for artificial hands, Sensors and Actuators 141 (2008) 548-557.

DOI: 10.1016/j.sna.2007.10.025

[4] H. X. Hu et al, Predicting the preferential sites to liquid droplet erosion of the bellows assemblies by CFD, Nuclear Engineering and Design 241 (2011) 2295-2306.

DOI: 10.1016/j.nucengdes.2011.03.045

[5] Y. Jingzhou, et al, A Hyper – redundant continuous robot, IEEE International Conference on Robotics and Automation, (2006) 1854-1859.

DOI: 10.1109/robot.2006.1641976

[6] M. Ono, S. Kato, A study of an earthworm type inspection robot movable in long pipes, Int. J. of Advanced Robotic System 7 (2010) 85-90.

DOI: 10.5772/7248

[7] K. Kawashima et al, Development of coarse/fine dual stage using pneumatically driven bellows actuator and cylinder with air bearings, Precision Engineering 34 (2010) 526-533.

DOI: 10.1016/j.precisioneng.2010.02.005

[8] F. Badano et al, Control of a planar fine positioner actuated by metal bellows, Automatica 30 (1994) 1677-1691.

DOI: 10.1016/0005-1098(94)90071-x

[9] Servometer Electrodeposited Bellows Catalog.

[10] V. S. Jisa et al, Sisteme de actionare pe baza de silfoane, a XIII-a Conferinta Nationala, multidisciplinara–cu participare internationala Profesorul Dorin Pavel – fondatorul hidroenergeticii romanesti, (2013) 439-444.
