Evaluation of Shear Strength of Concrete Beams with GFRP Reinforcement

Abstract:

This research presents an experimental study related to the shear behavior of simply supported reinforced concrete beams reinforced with Glass Fiber Reinforced Polymer (GFRP) bars. Four concrete beams reinforced with GFRP bars and four control concrete beams reinforced with steel bars were tested until failure. In order to realize the occurrence of shear failure, all tested beams were designed with longitudinal reinforcement only and without shear reinforcement. The test variables used in this study were the concrete strength, f'c, and longitudinal reinforcement ratio, ρ. The crack patterns, location of the diagonal crack and angle of the diagonal crack were also observed during the test. The shear design equations obtained from the codes and references were used to evaluate the data obtained from the test. Finally, based on the data obtained from experimental and theoretical analysis, comments and recommendation on the shear strength equations were suggested.

• Periodical: Applied Mechanics and Materials (Volume 660)
• Pages: 603-612
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.660.603
• Online since: October 2014
• Authors: Imohamed Ali*, Abdul Aziz Abdul Samad, Noridah Mohamad, Ghusen Al-Kafri, Ahamad Mohmmed
• Keywords: Concrete Beams, GFRP Bars, Shear Cracks, Shear Strength

References

[1] Pilakoutas, K. (2000), Composites in Concrete Construction in Gdoutos A., Pilakoutas K. and Rodopoulos C. (Eds), Failure Analysis of Industrial Composite Materials, McGraw-Hill, Professional Engineering, 449-497.

[2] Nawy, E.D. (2003). Reinforced Concrete: A Fundamental Approach., Prentice Hall. Fifth Edition, New Jersey: Pearson Education, Inc. 149 – 156.

[3] MacGregor, J. and Wright, J. K. (2005). Reinforced Concrete Mechanics and Design., 4th. Ed. New Jersey: Pearson Prentice Hall. 209 – 216.

[4] Thamrin, R., Abdul Aziz Abdul Samad, David, Y. E,. Abdul Hamid, N, A,. Imohamed Ali,. Experimental Study On Diagonal Shear Cracks Of Concrete Beams Without Stirrups Longitudinally Reinforced With GFRP Bars,. Proceedings fib Symposium PRAGUE 2011, ISBN 978-80-87158-29-6 Session 5-4: Composites and Hybrids.

[5] Thamrin, R., Abdul Aziz Abdul Samad, Noor Azlina Abdul Hamid (2009). Evaluation On Shear Capacity And Tension Force Of Longitudinal Reinforcement Of RC Beams With FRP Bars., Proceedings of APSEC 2009 & EACEF 2009. 2. 424-430.

[6] Thamrin, R. and Kaku, T. (2007). Bond Behavior of CFRP Bars in Simply Supported Reinforced Concrete Beam with Hanging Region., Journal of Composites for Construction. Vol. 11. 129 – 137.

DOI: 10.1061/(asce)1090-0268(2007)11:2(129)

[7] ACI (2003), ACI 440. 1R-03 – Guide for the Design and Construction of Concrete Reinforced with FRP Bars, ACI Committee 440, American Concrete Institute, Farmington Hills, MI, USA.

DOI: 10.1061/40753(171)158

[8] ACI Committee 440. Guide for the design and construction of concrete reinforced with FRP bars. ACI 440. 1R-06. American Concrete Institute, Farmington Hills, Michigan; 2006. p.41.

DOI: 10.14359/51700867

[9] ISIS-M03-01, 2001. Reinforcing Concrete Structures with Fiber Reinforced Polymers. The Canadian Network of Centers of Excellence on Intelligent Sensing for Innovative Structures, University of Winnipeg, Manitoba, Canada, 81p.

[10] Japan Society of Civil Engineers (JSCE), Recommendation for design and construction of concrete structures using continuous fiber reinforcing materials, concrete engineering series no. 23; 1997. p.325.

[11] ACI Committee 318, Building Code Requirements for Structural Concrete (318-02) and Commentary (318R-02). American Concrete Institute, Farmington Hills, Michigan; 2002. p.443.

DOI: 10.1061/(asce)1076-0431(1996)2:3(120.3)

[12] Tureyen, A. K., and Frosch, R. J. (2002); Shear Tests of FRP-Reinforced Concrete Beams without Stirrups, ACI Structural Journal, V. 99, No. 4, July-Aug. 2002, pp.427-434.

DOI: 10.14359/12111

[13] CSA A23. 3-94, Design of Concrete Structures for Buildings, Canadian Standards Association, Rexdale, Ontario, Canada, 1994, 220 pp.
