Development of Mobile Deformable Barrier for Side Impact Crashworthiness Evaluation in ASEAN New Car Assessment Programme (ASEAN NCAP)

Abstract:

Side impact crash test simulates a road crash wherein the side of a vehicle is being impacted, either perpendicularly or at an angle, by the front-end of another vehicle of about similar mass. In Malaysia, this crash configuration is the second leading cause of fatality and injury in road crashes after frontal collision. Extensive research have been carried out worldwide in order to mitigate occupant injury in side impact collision through provision of side impact protection system in vehicle such as side impact airbags and side door bars. As a result, various global regulations and consumer test requirements concerning side impacts have been established to evaluate the effectiveness of the said protection system. Recently, the Malaysian government has implemented the United Nation’s regulation pertaining to side impact protection (UN Regulation 95) for new passenger vehicles in the country. Hence, as a newly established automobile safety rating programme in the region, the ASEAN New Car Assessment Programme (ASEAN NCAP) has a plan in the pipeline to implement UN R95 side impact crash test tentatively in its future assessment scheme. A mobile deformable barrier (MDB) was developed as a preparation towards implementing the ASEAN NCAP’s side impact crashworthiness evaluation. This paper describes characteristics and requirements of the UN R95 as well as the development of the MDB according to the regulation. Several tests and improvements were conducted to ensure the MDB is reliable and having high repeatability for testing.

• Periodical: Applied Mechanics and Materials (Volume 663)
• Pages: 562-566
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.663.562
• Online since: October 2014
• Authors: Aqbal Hafeez Ariffin*, Mohd Syazwan Solah, Hamzah Azhar, Mohd Hafzi Mohd Isa, Mohd Khairudin Rahman, Zulhaidi Mohd Jawi, Noor Faradila Paiman, Yahaya Ahmad, Khairil Anwar Abu Kassim
• Keywords: ASEAN NCAP, Crash Test, Crashworthiness, Mobile Deformable Barrier (MDB), Side Impact, UN Regulation 95

References

[1] C.J. Kahane, An Evaluation of Side Impact Protection, FMVSS 214 TTI(d) Improvements and Side Air Bags. National Highway Traffic Safety Administration, DOT HS 810748: Washington D.C., USA (2007).

[2] L. Jakobsson, M. Lindman, B. Svanberg, H. Carlsson, Real world data driven evolution of Volvo cars' side impact protection systems and their effectiveness, Annals of Advances in Automotive Medicine. 54 (2010) 127-136.

[3] M.I. Mohd Hafzi, A.K. Khairil Anwar, R. Mohd Khairudin and S.V. Wong, The accident analysis of two-vehicle side impact crashes in Malaysia, In: Proceedings of International Conference of Crashworthiness, Washington DC, USA, September 22-24, (2010).

[4] M.I. Mohd Hafzi, Z.A. Ahmad Noor Syukri, A. Aqbal Hafeez, M.J. Zulhaidi and A.K. Khairil Anwar, Scenario, test requirements and occupant protection concerning side impacts: an overview, In: Proceedings of MIROS Road Safety Conference (ROSCON), Kuala Lumpur, Malaysia December 8-9, (2010).

[5] Information on http: /www. cbt. com. my/2012/04/13/adopting-unece-r94-and-r95-a-car-plant-is-no-nasi-lemak-stall/ (Accessed September 2013).

[6] UN Regulation No. 95, Agreement (11 November 2011), United Nations, E/ECE/324/Rev. 1/Add. 94/Rev. 1-E/ECE/TRANS/505/Rev. 1/Add. 94/Rev. 1.

[7] Information on http: /www. aseancap. org (Accessed September 2013).

[8] M. Ueno, T. Harigae, H. Ohmae, T. Uchimura and E. Fujiwara, Development of moving deformable barrier in Japan: part 2, In: Proceedings of the 16th International Technical Conference on the Enhanced Safety of Vehicles (ESV), 1827-1834, May 31-June 4, 1998: Windsor, Ontario, Canada.

[9] Information on http: /www. euroncap. com (Accessed September 2013).

[10] CARHS Safety Companion 2013. CARHS GmbH, Alzenau, Germany (2013).

[11] Information on http: /www. cellbond. net (Accessed September 2013).

[12] Directive 96/27/EC (20 May 1996), Protection of occupants of motor vehicles in the event of a side impact and amending Directive 70/156/EEC, The European Parliament and of the Council of the European Union.
