An Equivalent Modeling for Synthesis Load of Distributed Network with Small Hydropower

Abstract:

A distributed network with small hydropower is taken as research subject, and in PSASP environment a simulation network is constructed, which is based on the network’s connection mode and operation data. At first, this paper give a description of 3rd mode of small hydropower generator, and generalize common analysis methods of synthesis load, and on this basis lists three means that used for aggregating parameters, then choose weighted average method to aggregate necessary parameters of Small hydropower generators. Secondly, the operation data is fully used to determine the equivalent impedance of the network. Finally, in order to verify the accuracy and feasibility of the method raised by the paper, the author make a comparison of small hydropower generators’ relative rocking curve before and after equivalence, meanwhile, analyzes change regulation of active power in contact line before and after the equivalence.

• Periodical: Applied Mechanics and Materials (Volume 666)
• Pages: 119-124
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.666.119
• Online since: October 2014
• Authors: Zai De Xu, Guo Cheng Sun, Ben Ren Pan, Ning Xu, Chao Qun Li, Hong Zhong Ma
• Keywords: Aggregation of Parameters, Distributed Small Hydropower, Impedance of Network, Synthesis Load

References

[1] Yi Zhongdong, Zhu Yongqiang. power generation technology of Renewable energy. Beijing: Chinese water conservancy and Hydropower Press. 2010, 5. 116-118.

[2] Dusonchet L, Massaro F, Telaretti E. Transient stability simulation of a fixed speed wind turbine by Matlab/Simulink, In: International Conference on Clean Electrical Power．Capri, 2007, 651-655.

DOI: 10.1109/iccep.2007.384308

[3] Zhu Jianguo, Li Xianshan, Hu Xiangyong. Modularization for whole dynamic process simulation of hydro-generators[J]. Journal of China Three Gorges University(Natural Sciences). 2006, 28(1): 27-3.

[4] Yang Fu, Liang Jun, Niu Qingda. A practical method of parameter aggregation for power system dynamic equivalence[J]. Power System Protection and Control. 2013, 23(4): 23-25.

[5] Zhang Yuansheng, Li Xinran, Xiao Yuanyuan. A practical method for determining parameters of load model of distributed network with small hydro power[J]. Advanced Technology of Electical Engineering and Energy, 2012, 31(4): 83-84.

[6] Qian Jun. Studies on composite load modeling of distribution network considering distributed generation[D]. (2010).

[7] Ju Ping, He Xiaojun, Huang Li, et al. Model structures and parameter estimation Of generalized loads[J]. Automation of Electric Power Systems. 2006, 30(23): 11-13.

[8] Wei Wei, Ding Lijie. Study on small hydropower equivalence and parameter identification based on outlet line information. Sicuan Electric Power Technology. 2013, 36(5): 20-21.

[9] Ni Yixin, Chen Shousun, Zhangbaolin. Dynamic theory and analysis of power system[M]. Beijing: Tsinghua University Press, (2002).

[10] IEEE/CIGRE joint task force on stability terms and definition. Definition and classification of power system stability. IEEE Trans on Power Systems, 2004, 19(2): 1387-1401.

DOI: 10.1109/tpwrs.2004.825981

[11] Nath R, Lamba S S. Development of coherency-based time-domain equivalent model using structure constraints[J]. Generation, Transmission and Distribution, IEE Proceedings C, 1986, 133(4): 165-175.

DOI: 10.1049/ip-c.1986.0029

[12] Wang Min, Wen Jinyu, Hu Wenbo. A dynamic equivalent modeling for regional small hydropower generator group[J]. Power System Protection and Control. 2013, 41(17): 2-4.

[13] A. R. Messina,V. Vittal. Nonlinear, non-stationary analysis of interarea oscillations via Hilbert Spectral analysis．IEEE Transactions on Power Systems, 2006, 21(3)：1234-1241.

DOI: 10.1109/tpwrs.2006.876656

[14] Nether P. Two-dimensional transient model of a cascaded micro-tubular solid oxide fuel cell fed with methane．Journal of Power Sources, 2006, 157(7): 325-334.

DOI: 10.1016/j.jpowsour.2005.07.077

[15] Nelson D B, Nehrir M H, Wang C, Unit sizing and cost analysis of stand alone hybrid wind/PV/fuel cell power generation system. Journal of Renewable Energy, 2006, 31(10)1641-1656.

DOI: 10.1016/j.renene.2005.08.031
