Mixed Lubrication and Friction Power Loss of Piston Ring Pack

Abstract:

With consideration of asperity contact, the minimum oil film thickness and friction power loss are calculated by simultaneous solution of the dynamics, blow-by and lubrication of piston ring pack. Take the piston ring pack in the first cylinder from the free end of a six-cylinder diesel engine for example, results show that the asperity contact takes place at all of the compression rings and oil ring; the minimum oil film thickness is 1.04μm at the top ring; the total friction loss power is 0.94kW, the top ring accounts for 37.2%, the second ring accounts for 33.0%, the oil ring accounts for 29.8%.

• Periodical: Applied Mechanics and Materials (Volumes 668-669)
• Pages: 205-208
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.668-669.205
• Online since: October 2014
• Authors: Xiao Ri Liu*, Guo Xiang Li, Shu Zhan Bai, Yu Ping Hu
• Keywords: Dynamic, Frictional Power Loss, Mixed Lubrication, Piston Ring Pack

References

[1] P. Liu, C. Q. Yuan, Z. W. Guo: Acta Armamentar II Vol. 22 (2012), p.149 (in Chinese).

[2] X. He, X. C. Wang, Q. Li, et al: Lubrication Engineering Vol. 38 (2013), p.1 (in Chinese).

[3] K. Liu, C. L. Gui: Journal of Xian Institute of Technology Vol. 14 (1994), p.1 (in Chinese).

[4] Z. M. Deng, G. Y. Ouyang, Y. X. Li, et al: Lubrication Engineering Vol. 36 (2011) , p.60 (in Chinese).

[5] N. Patir, H. S. Cheng: Transcations of the ASME Vol. 100 (1978), p.12.

[6] J. A. Greenwood, J. H. Tripp: Proceedings of the Institution of Mechanical Engineers Vol. 185 (1970), p.625.

[7] G. Z. Wang, Y. M. Hao, W. R Ma, et al: Chinese Internal Combustion Engine Engineering Vol. 31 (2010), p.63 (in Chinese).

[8] Y. Z. Hu, H. S. Cheng, T. Arai, et al: Journal of Tribology, Trans. ASME Vol. 116 (1994), p.470.
