A Low Noise Power Design for Electrical Impedance Tomography System

Abstract:

This paper describes a quality power module design for Biological Electrical Impedance Tomography (BEIT) system based on FPGA. As the electrical signals on the boundary of subject are too weak to measure effectively, it is essential to design a data acquisition system with high SNR and extremely low noise. This paper is focus on the power module design because the quality of the power module impacts the performance of the data acquisition system directly. The BEIT system needs several kinds of power supply to work effectively, such as 12V, 5V. In this paper, the power module is supplied by DC18V, using Buck-type DC/DC and LDO technologies, a set of independent power supply scheme is carried out, and provides stability and low noise power sources. The expected powers with ripple less than 20mV are achieved, which can preferably meet the BEIT system power supply requirements.

• Periodical: Applied Mechanics and Materials (Volumes 670-671)
• Pages: 1159-1162
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.670-671.1159
• Online since: October 2014
• Authors: Yan Yan Guo, Xiao Yan Chen, Yong Zheng Yang*
• Keywords: Buck DC/DC, Electrical Impedance Tomography, Low Ripple Voltage, Power System

References

[1] S Khan, A Borsic, Preston Manwaring, Alexander Hartov and Ryan Halter: IOP Science. (2013).

[2] Huaxiang Wang, Ziqiang Cui: Chinese Journal Of Electron Devices, Vol. 30 (2007), p.91.

[3] Xiaoyan Chen, Jiani Wu: Applied Mechanics and Materials, 2011, 48-49: 537-540.

[4] Aiping Zhou: Power Supply Technologies and Applications, Vol. 5 (2013), p.125.

[5] Yujie Fang, Binghua Su, Lingxia Hang: Vol. 35, No. 10, May (2012).

[6] Vahid Samavatian, Ahmad Radan: Electrical Power and Energy Systems 63 (2014) 446-454.

[7] Information on http: /www. ti. com. cn.

[8] Dongpo Chen, Lenian He, Xiaolang Yan: Journal of Electronics & Information Technology. Vol. 28, No. 8 August (2006).

[9] Information on http: /www. xilinx. com.
