Study on Volumetric Tool Wear Measurement Using Image Processing

Abstract:

This paper presents a method of measuring the volumetric tool wear by use of the image processing technique. A single CCD camera based stereo vision system is built to acquire the image pair. The crater wear’s boundary of the cutting tool is then detected, and then the 3D volumetric shape of the worn region on the rake face is reconstructed through the developed image matching algorithms, and the crater’s volume and depth is estimated. A Matlab software system is developed to perform image acquisition, calibration, image rectification, image adjustment, stereo matching, crater’s depth estimation, and the representation of the volumetric tool wear. The feasibility of the proposed method is verified through experiments.

• Periodical: Applied Mechanics and Materials (Volumes 670-671)
• Pages: 1194-1199
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.670-671.1194
• Online since: October 2014
• Authors: Jian Cheng Liu*, Guang Xi Xiong
• Keywords: Crater Wear, Cutting Tool, Image Process, Stereo Vision System, Volumetric Tool Wear

References

[1] G. Xiong, Jiancheng Liu, A, Avlia, Cutting Tool Wear Measurement by Using Active Contour Model based Image Processing, Mechatronics and Automation (ICMA), 2011 International Conference (IEEE), pp.670-675, Aug. (2011).

DOI: 10.1109/icma.2011.5985741

[2] W. H, Wang, G. S, Hong Flank wear measurement by a threshold independent method with sub-pixel accuracy, 2006, Int J Mach Tools Manuf 46(2): 199–207 doi: 10. 1016/j. ijmachtools. 2005. 04. 006.

DOI: 10.1016/j.ijmachtools.2005.04.006

[3] C. Kurada, D. Bradley, A review of machine vision sensors for tool condition monitoring, Computers in Industry, August (1996).

DOI: 10.1016/s0166-3615(96)00075-9

[4] H.V. Ravindra, Y.G. Srinivasa b, R. Krishnamurthy b, Acoustic emission for tool condition monitoring in metal cutting, India (1997).

DOI: 10.1016/s0043-1648(97)00137-3

[5] F. Giusti, M. Santochi, G. Tantussi, On-line sensing of flank and crater wear of cutting tools,, Ann. CIRP 36 (1) 41-44, (1987).

DOI: 10.1016/s0007-8506(07)62549-9

[6] Y. Maeda, H. Uchida, A. Yamamoto, Contour mapping of cutting tool face with the aid of digital image processing technique, Bull. Jpn. Soc. Prec. Eng. 21(2) 136-138, 198.

[7] Min-yang Yang a and Oh-dal Kwon, Crater wear measurement using computer vision and automatic focusing, Journal of Materials Processing Technology362-367, (1996).

DOI: 10.1016/0924-0136(95)02208-2

[8] S. Karthik. B. Chandra, S. Das, Ramamoorthy, 3D Tool Wear Measurement and Visualisation Using Stereo Image, 1997, Int. J. Math. Tools Manufact. Vol. 37, No. II, pp.1573-1581, (1997).

DOI: 10.1016/s0890-6955(97)00023-0

[9] K. Niranjan Prasad, B. Ramamoorthy, Tool wear evaluation by stereo vision and prediction by artificial neural network, Journal of Materials Processing Tech. Vol. 112, pp.43-52, (2001).

DOI: 10.1016/s0924-0136(00)00896-7

[10] L. Stefano, M. DiMarchionni, S. Mattoccia, A fast area-based stereo matching algorithm, Proceedings from the 15th International Conference on Vision Interface, 983-1005, (2004).

DOI: 10.1016/j.imavis.2004.03.009

[11] C. Sun, Fast stereo matching using rectangular subregioning and 3D Maximum-surface Techniques, International Journal of Computer Vision, April 2002, Volume 47, pp.99-117.

DOI: 10.1109/smbv.2001.988762
