Analysis of the Sensorless PMSM Control Technique in the Full Speed Section

Abstract:

A novel position sensorless control strategy integrated with full section and high precision for a permanent magnet synchronous motor (PMSM) applied to wind power pitch was proposed in the paper. Based on high frequency signal, where three-phase triangular carrier spwm is injected and the state current response is detected to accurately estimate the rotor position in the still and low speed, which doesn’t rely on the non-ideal features. Based on BEF PMSM mathematic model, the phase locked loop technique is used to accurately detect the rotor position in the middle and high speed. the Finally, experiment on a 10 KW pith system demonstrates that the proposed method is effective and is capable of achieving more accurate control in the full speed section.

• Periodical: Applied Mechanics and Materials (Volumes 672-674)
• Pages: 1191-1196
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.672-674.1191
• Online since: October 2014
• Authors: Hong Gang Li*, Chao Feng Li, Rui Jie Zhao, De Lin Liu, Hong Hao Zhu
• Keywords: Full Speed Section, Permanent Magnet Synchronous Motors (PMSM), Position Sensorless Control, Precision

References

[1] Jing Hua-bin，Liao. LiQing . Control of Speed Sensorless Permanent Magnet Synchronous Motor Based on MARS[J] ELECTRIC DRIVE FOR LOCOMOTIVES，2007, 1 (10): 33-36.

[2] HE Yulin, HUANG Shuai, DU Jing, SU Dongxu, LI Jun. Variable pitch control of wind turbine based on feed forward[J]. Power System Protection and Control, 2012, 40(3): 15-20.

[3] Wang Wenliang, Ge Baoming, Bi Da-qiang. Energy storage based direct-drive permanent magnet synchronous wind power control system[J]. Power System Protection and Control, 2010, 38(14): 43-48.

DOI: 10.1109/powercon.2010.5666732

[4] Nian Heng，He Yikang，Huang Lei. Position Sensorless Operation of PMSM Using the Field-circuit Coupled Solution[J]．Proceedings of the CSEE，2008, 6(18): 104-109.

[5] LiuYi，He Yikang, Qin Feng．Investigation of rotor saliency-tracking based sensorless vector control drive for PMSM[J]．Proceedings of the CSEE，2005。25(17)：121—126.

[6] Kyu-Wang Lee, Doo-Hee Jung, and In-Joong Ha。An Online Identification Method for Both Stator Resistance and Back-EMF Coefficient of PMSMs Without Rotational Transducers[J]。IEEE TRANSACTIONS ON INDUSTRIAL ELECTRONICS, 2004, 51(2): 507-510.

DOI: 10.1109/tie.2004.825280

[7] Bilal G umus, Mehmet O zdemir. Sensorless vector control of a Permanent magnet synchronuous motor with fuzzy logic observer[J]。Electrical Engineering, 2006, 88: 395–402.

DOI: 10.1007/s00202-005-0301-7

[8] Ning Yi，Li Honggang，Li Fusheng, Tao Xuejun. Modeling and Simulation of Wind Rotor for Variable-speed Wind Turbine[J]. Taiyangneng Xuebao, 2012, 33(6): 1010-1013.

[9] Li Chao-feng , Li Hong-gang, Tao Xue-jun, Zhao Rui-jie, Liu De-lin. Simulation and Analysis of Wind Turbine Variable Pitch Torque and Control System。The 2nd International Conference on Electrical and Control Engineering , 2011. 9 : 1266-1269.

DOI: 10.1109/iceceng.2011.6058022

[10] SONG Xin-fu, LIANG Bo. Wind power system pitch control based on fuzzy self-learning emendation control theory[J]. Power System Protection and Control, 2009, 37(16): 50-53.

[11] Yu Yan-jun, Wang Ben-zhen, Zhu Chun-bo . Analysis of Rotor Position Estimated Error for IPM SM Using Carrier Frequency Component M ethod[J]. J]. Proceedings of the CSEE, 2012, 12(25): 146-154.

[12] Wang Ben-zhen, Deng Kan-yi, Yu Yan-ju. DC Bus Voltage Effect Analysis to Sensorless Control Based on Carrier Frequency Component Method[J]. micromotor, 2011: 10-12.
