Single Event Effects Testing of Xilinx Zynq-7010 SoC with ²³⁹Pu Alpha Irradiation

Abstract:

Estimating the radiation sensitivity and radiation response of individual electronic units embedded in System on chip (SoC) is important for SoC error rate predicting and fault tolerant system designing. In this paper, the experimental techniques for detecting the single event effects (SEE) of SoC were introduced. The test system has been established and the irradiation experiments have been performed for testing SEE of Xilinx Zynq-7010 SoC with ²³⁹Pu alpha radiation source. Several single events functional Interrupt (SEFI) of some typical registers within the SoC sample were detected after receiving the total fluence of 6.101. In the end, the mechanisms of SEFI induced by alpha irradiation on SoC were discussed and analyzed.

• Periodical: Applied Mechanics and Materials (Volume 678)
• Pages: 268-273
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.678.268
• Online since: October 2014
• Authors: Xue Cheng Du, Shu Huan Liu*, Chao Hui He, Xin Du, Yong Hong Li, Yao Zhang, Wei Chen, Xin Zan Liu, Dong Sheng He
• Keywords: Single Event Effects (SEE), Single Event Functional Interrupt (SEFI), System on Chip (SoC)
