Modal Analysis on a Runner Chamber for a Large Hydraulic Bulb Tubular Turbine

Abstract:

The vibration was severe for a runner chamber of a large hydraulic bulb tubular turbine, which caused some cracks. The PRO/E software was adopted to establish a 3D model of the runner chamber. Based on ANSYS Workbench V14.5, a modal analysis was done. Its natural frequencies and modal shapes were obtained. The influence on modal characteristics with the runner chamber’s structure was discussed. The study shows that the reinforce stiffener’s thickness, the circumferential endlessband and their thicknesses have few effect on the modal characteristics of the runner chamber, the latticed reinforce stiffener has more effect on the modal characteristics. These results will provide the basis for product optimum design, so that its natural frequencies stagger these frequencies of field vibration, the resonance and the crack do not occur in the runner chamber.

• Periodical: Applied Mechanics and Materials (Volume 678)
• Pages: 561-565
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.678.561
• Online since: October 2014
• Authors: Chang Zheng Huang*, Jin Li, Zu Chao Yang, Zhuo Wei Xu
• Keywords: Finite Element Analysis (FEA), Modal Analysis, Runner Chamber, Tubular Turbine

References

[1] GAO Lin, JIANG Guang-bing. Analysis and Treatment for Crack in Runner Chamber of Generating Set 3 for Honghuan Hydropower Station[J]. Guangdong Water Conservancy and Hydropower, 2011, (11): 32-34.

[2] HUANG Song-jiang. Analysis and Treatment for Crack in Runner Chamber's Stiffener of Generating Set 2 for Gongchuan Hydropower Station [J]. SMALL HYDRO POWER, 2013, (4): 91-92.

[3] WANG Ze- hong. Causes Analysis and Treatment for Over Vibration in Runner Chamber of Jinyintai Hydropower Station[J]. HongShui River , 2013, 32(2): 72-77.

[4] Li Hongwei, Yu Wentao, Liu Shuqin. Modal Analysis and Design of Maglev Flexible Rotor with ANSYS [J]. Chinese Journal of Mechanical Engineering, 2014, 25(11): 1447-1452.

[5] Zhong Su. Suggestions on the design of the anti-vibration and crack-proof of turbine [J]. Water Power, 2005, 31(2): 54-57.

[6] XIAO Zhengming, QIN Dationg, WU Wenhui, ZHOU Zhigang. Testing and modal analysis on multi-stage planetary gearbox housing of shield tunnelling machine[J]. Journal of Chongqing University, 2012, 35(7): 37-43.

[7] ZHAO Xiao-li, LIU Ying-lin, WANG Biao. Structure Modal Analysis of Belt Conveyor Large Drive Roller[J]. Coal Mine Machinery, 2012, 33(12): 91-92.

[8] LI Jian, JIANG Zhen-ting , DONG Xu. Analysis and vibration suppression of power-on-live manipulator based on ANSYS WORKBENCH[J]. Manufacturing Automation, 2014, 36(1): 48-52.

[9] FAN Zhong-ting, WU Mei-ping, SHI-Jian. Modal Analysis and Dynamic Characteristics Optimization of Large Floor-Type Milling and Boring Machine Spindle Box[J]. Modular Machine Tool & Automatic Manufacturing Technique, 2014, (2): 121-124.

[10] SUN Hong-chun, WU Shao-kun ZHANG Da-long. Cracks Damage of the Steel Bar Based on Experimental Modal Analysis[J]. Journal of Northeastern University(Natural Science, 2013, 34(5): 691-694.

[11] MA Shu-mei, CHEN Yang-yang, CAI Hui-sen, Li Ai-ping. Modal analysis of stator core for large size motor based on ANSYS[J]. JOURNAL OF MACHINE DESIGN, 2014, 31(2): 24-27.

[12] MA Ya-long. Research on Path Optimization of Hydraulic Support Based on Genetic Algorithms[J]. Coal Mine Machinery, 2013, 34(6): 124-125.
