Simulation Research for the Excavation Stability of IV Brittle Rock Based on Vault Settlement Effect

Abstract:

Due to the brittle rock deformation is not obvious, and the destruction process has the features of sudden and concealment, it is often neglected in the field during construction. In this paper, Brittle rock was selected as the research object. Using the vault subsidence as monitoring parameters, the excavation process was simulated in single line tunnel by the finite element analysis tool of ANSYS, we obtain the maximum displacement of brittle rock and stress variation with time. Then the subsidence effect of different buried condition were analyzed, to determine the stability period of IV Brittle surrounding rock. The research results can be used to guide the development of the monitoring standard, in underground engineering construction of the brittle rock.

• Periodical: Applied Mechanics and Materials (Volume 681)
• Pages: 209-213
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.681.209
• Online since: October 2014
• Authors: Ke Ling Liu, Long Guo
• Keywords: Brittle Rock, Excavation Stability, Vault Settlement Effect

References

[1] TB 10003-2005, Code for design on tunnel of railway [S].

[2] Li Xiao-Hong, Wang Hong-Tu, Jia Jian-Qing , Ultimate displacement discrimination of stability and reliability analysis of surrounding rocks of tunnel and underground engineering[J], Rock and Soil Mechanics, 2005, (6): 850-854.

[3] Shi Jin-Feng, Zhang Ying-Long, FEM Analysis of Rock Stability on Super Section Tunnel[J], Chinese Journal of Underground Space and Engineering, 2005, (2): 228-230.

[4] Chen Xian-Guo，Gao Bo, 2D FEM NUMERICAL SIMULATION FOR CLOSELY-SPACED PARALLEL TUNNELS IN METRO[J], Chinese Journal of Rock Mechanics and Engineering, 2002, (9): 1330-1334.

[5] TB J449-2005, Code for design on tunnel of railway [S].

[6] Li quan, Application of ANSYS in Civil Engineering, BeiJing: Posts and Telecom Press, 2005: 180-186.
