Out-of-Plane Stability Analysis for Crane Jib with Single Cable Considering Lateral Flexibility of the Cable Fixed Joint

Abstract:

The out-of-plane stability of crane jib is studied considering the lateral flexibility of the fixed joint. The analytical expression of the out-of-plane buckling characteristic equation for the crane jib with single cable is obtained by establishing the bending deflection differential equation of jib under the instability critical state with the method of differential equation. The equilibrium equation of the fixed point in the lateral direction is introduced to solve the differential equation besides the boundary conditions. The analytical results obtained agree very well with the finite element method (FEM) results. To consider the lateral flexibility of the cable fixed joint, a dimensionless stiffness coefficient measuring the lateral constraint was introduced to derive the out-of-plane buckling characteristic equation. The degeneration forms of the characteristic equation under the limit cases of zero lateral stiffness, infinite lateral stiffness are further discussed. And the influence of the lateral stiffness of fixed joint on the stability of jib is investigated. It is shown that the increase of the lateral stiffness will significantly improve the buckling load of the crane jib especially when the lateral stiffness is very small.

• Periodical: Applied Mechanics and Materials (Volume 685)
• Pages: 240-244
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.685.240
• Online since: October 2014
• Authors: Peng Lan, Teng Fei Wang, Nian Li Lu
• Keywords: Cable Fixed Joint, Crane Jib, Deflection Differential Equation, Lateral Flexibility, Out-of-Plane Stability

References

[1] WU Changzhen. The analysis of the level jib with two tension calbes[J]. Construction Machinery and Equipment, 1987, 04: 14-21.

[2] ZHANG Peng, ZHOU Fan. The overall stability analysis of the crane jib with two tension cables[J]. Construction Machinery, 1990, 09: 10-16.

[3] LU Nianli, ZHANG Liqiang, GU Dimin. Equivalent support method of stability calculation of compression member under nondirectional force and its application in analysis of boom[J]. Construction Machinery 1996, 07: 15-17+2.

[4] LU Nianli, LI Yishen, GU Dimin. The critical force for the crane jib under the action of cable tension at the end point[J]. Water Conservancy & Electric Power Machinery, 1996, 02: 15-18.

[5] MENG Xiaoping, LU Nianli, LI liang. Crane jib out-of-plane stability characteristic equation and its use under follower forces[J]. Journal of Harbin University of Civil Engineering and Architecture, 1997, 02: 99-103.

[6] Timoshenko SP, Gere JM. Theory of elastic stability [M]. 2nd ed. New York: McGraw-Hill, (1961).
