The Design of Intelligent Watt-Hour Meter Based STM32 System

Abstract:

In view of limitations function, cost and application in domestic meter at present, this paper was designed the low power consumption, low cost smart meters and PC system based on microprocessor MSP430F4794. It supports multi rate, step rate and power factor influence factor of electricity metering method, and can realize the real-time clock, timing backup data, monitoring the temperature and humidity of the environment and other functions, has the ability to forecast the next period of time energy consumption and carbon dioxide emissions of electrical appliances. Combined with the PC software, the backup data of smart meters to report, detailed list, and the data curve method is presented to the user, and facilitate to analysis of user. The whole embedded in smart meters and the host computer system provides a good human-computer interface, can realize the user personalized service configuration and software calibration function.

• Periodical: Applied Mechanics and Materials (Volume 686)
• Pages: 185-189
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.686.185
• Online since: October 2014
• Authors: Hong Zhang*
• Keywords: MSP430, No Power, Power Factor, Smart Meter

References

[1] Li Jing, Yang Yihan, Wen Bin, et al. Review of electric energy metering system[J]. power system protection and control. 2009, 37 (11): 130-134.

[2] Zhang Caifen, Chi ximei. Electronic energy meter and electric meter performance comparison analysis[J]. Inner Mongolia electric power technology, 2006, 24 (S3): 133-135.

[3] Li Feng. The analysis of structure and error of electronic energy meter[J]. instrument standardization and metrology. 2006, (4): 29-30.

[4] China State Grid Corp. Overview of smart grid development in abroad[J]. Internet of things technology. 2012, (1): 4-8.

[5] Wang Xinyi. Research and design of multi function intelligent electric meter[D]. Wuhan: Wuhan University of Technology, (2011).
