Research on NC Machining and Accurate Modeling of Curve Bevel Gear

Abstract:

This paper first analyzes the NC simulation and NC machining process of curve bevel gear, and provides the basic equations and the formulae in detail based on the CNC 3 axis linkage machine tool cutting. Directly to takes the rotation angle of the work gear as machine tool motion parameters, the axes of other motion work piece express the gear angle function. Finally, according to the characteristics of curve bevel gear, we select reasonable processing technology, setting processing parameter of curve bevel gear, then test the tool path simulation and program processing, and finally the use of CNC milling machine with three linkage process curve bevel gear.

• Periodical: Applied Mechanics and Materials (Volume 686)
• Pages: 497-502
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.686.497
• Online since: October 2014
• Authors: Zhi Gang Liu*
• Keywords: CNC, Curve Bevel Gear, Machining Simulation
