The Theory and Realization Method for Weak-Magnetic Environment Simulation

Abstract:

The horizontal component of geomagnetic field is so weak in high latitude area that the magnetic navigation equipment available can not work, a method is introduced to simulate this weak-magnetic environment to by using artificial controllable magnetic field to neutralize geomagnetic horizontal component .Theoretical and simulation analysis is involved; using circular Helmholtz coils, an experimental device is made for the experimental research for weak-magnetic environment simulation. The experimental results show that this method has a certain feasibility

• Periodical: Applied Mechanics and Materials (Volumes 687-691)
• Pages: 3540-3544
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.687-691.3540
• Online since: November 2014
• Authors: Rui Feng Zhang*, Wei Chi, Lian Gan Jin
• Keywords: Controllable Weak Magnetic Field, Helmholtz Coils, Weak-Magnetic Environment

References

[1] Yang Xiaodong, Study on Geomagnetic Navigation Technology in High Latitude Area [J], Ship&Ocean Engingeering, 2010, 39(5) : 128-133.

[2] Zhang Chang-xin, Study on Magnetic Field of A Circular Current and Helmholtz Coils [J]. Journal of Anhui Normal University(Natrual Science) , 2004. 27(1) : 41-45.

[3] Kuang Xiangjun. Magnetic field of Square Current-Carrying Coil[J]. Physics and Engingeering , 2006, 16(1): 19-25.

[4] Tan Xi, The Magnetic Field Uniformity of Square Helmholtz Coils [J]. Optical Instrument，2012, 34(1): 39-44.

[5] SI Wenjian, Zhou Nan. Dynamic Simulation of Uniform Distribution of The Helmholtz Coil Magnetic Field on MATLAB [J]. Journal of Xuchang university, 2005, 29(5): 72-74.

[6] Peng Shuli. The Study on the Homoogeneity of Magnetic Field about the Geomagnetic Field Simulator [J]，Journal of Projectiles and Guidance, 2010, 30(4): 237-241.

[7] LIU Kun，Zhang Songyong. Analysis on magnetic field homogeneity of magnetic system on square Helmholtz coils[J].  Modern Electronic Technique，2012, 35(7): 190-193.
