A Novel Fault Diagnosis Method Based on Time-Frequency Image Recognition

Abstract:

A novel intelligent fault diagnosis method based on vibration time-frequency image recognition is proposed in this paper. First, Smooth pseudo Wigner-Ville distribution (SPWVD) is employed to represent the time-frequency distribution characteristics. Then, the features of time-frequency images are extracted by using locality-constrained linear coding (LLC) and spatial pyramid matching. Next, we use the support vector machine to identify these feature vectors for realizing intelligent fault detection. The promise of our algorithm is illustrated by performing above procedures on the vibration signals measured from rolling element bearing with sixteen operating states. Experimental results show that the proposed method can acquire higher diagnosis accuracy compared with the ScSPM method in rolling element bearing diagnosis.

• Periodical: Applied Mechanics and Materials (Volumes 687-691)
• Pages: 3569-3573
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.687-691.3569
• Online since: November 2014
• Authors: Wei Gang Wang, Zhan Sheng Liu
• Keywords: Intelligent Fault Diagnosis, Locality-Constrained Linear Coding, Rolling Element Bearing, Time-Frequency Image
