Study on the Resonance Amplitude of Bending-Torsion Coupling Vibration

Abstract:

When rotor exist eccentricity, there will be mutual effect between bending vibratory and torsion vibration. This kind of mutual effect will generate bending-torsion coupling vibration. At present, the majority research on the bending-torsion coupling vibration are focus on the nonlinear characteristics, but seldom on the coupling resonance amplitude of the bending-torsion coupling vibration. Given this situation, this article starts with resonance amplitude have further research on the bending-torsion coupling vibration. Firstly, a model of eccentric rotor with coupled bending and torsion vibrations was built and the vibration equation was solved by small parameter method. Then considering the forcing frequency and dynamic tress of the existing equipment can provide,the main resonance of bending-torsion coupling vibration stress relief was determined, and the mechanism of bending-torsion coupling vibration stress relief was put forward. Finally, the example demonstrated the theoretical analysis. The research provide thought and basis for the bending-torsion coupling vibration.

• Periodical: Applied Mechanics and Materials (Volumes 687-691)
• Pages: 394-397
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.687-691.394
• Online since: November 2014
• Authors: Zhuo Huai Guan*, Wen Jun Miao
• Keywords: Bending-Torsion Coupling Vibration, Coupling Resonance Amplitude

References

[1] Kato M, Ota H, Nkaamura S I. Torsional Vibration of a Rotating Shaft Driven by Constant Acceleration[J]. Paper Presented at ASIA APCIFIC VIBRATION CONFERENCE' 93. Kitakyushu, November 1993: 434-439. Reference to a book.

[2] Jingshuo LIU, Guangzhong LI. Research on Vertical Unbalance on the Coupling Flexural and Torsional Vibrations of Rotor[J]. Journal of Zhengzhou University (Engineering science), 2008, 9(29): 76-79. (in Chinese).

[3] Zhansheng Liu, Ying Cui. Study on Nonlinear Dynamics Characteristics of a Rotor with Coupled Bending and Torsional Vibrations[J]. Chinese Journal of Mechanical Engineering, 2003, 14(7): 603-605. (in Chinese).

[4] B. O. Bedoor. Modeling the coupled torsional and lateral vibrations of unbalanced rotors[J]. Computer methods in applied mechanic and engineering, 2001, 190,: 5999~6008. (in Chinese).

DOI: 10.1016/s0045-7825(01)00209-2

[5] Jecffott H. H. The Lateral Vibration of Loaded Shafts in the Neighborhood of a Whirling Speed-the Eeffet of Want of Balanee[J]. Phil. Mag., 1919, (37): 304.

[6] Chengbing He, Yujiong Gu. Coupled Flexural-torsion Vibration of Rotors with Unbalance Mass[J]. Proceedings of the CSEE, 2006, 26(14): 114-139. (in Chinese).
