Strong Shielding Interaction Analysis Using J-Integral

Abstract:

Numerical accuracy in assessing the strong shielding interaction that promotes cracking process based on continuum mechanics is presented in this paper. Crack interaction limit (CIL) and crack unification limit (CUL) are investigated based on strain energy release rate approach. The case of two interacting edge crack in finite body is simulated using finite element analysis and J-integral. As a result, the trend of CIL and CUL is presented to prove the limit and unification of energy release can be numerically shown at higher and lower crack-to-width ratio at two crack interval ratio b = 1 and b = 0. It can be concluded that the CIL and CUL is geometrically dependent.

• Periodical: Applied Mechanics and Materials (Volume 695)
• Pages: 511-515
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.695.511
• Online since: November 2014
• Authors: Ruslizam Daud*, M.S. Abdul Majid, Mohd Afendi, N.A.M. Amin, Ahmad Kamal Ariffin, Shahrum Abdullah
• Keywords: Crack Interaction, Crack Interaction Limit (CIL), Crack Unification Limit (CUL), J-Integral

References

[1] S. Loehnert and T. Belytschko, Crack shielding and amplification due to multiple microcracks interacting with a macrocrack, International Journal of Fracture, (2007) 1-8.

DOI: 10.1007/s10704-007-9094-1

[2] Z.D. Jiang, J. Petit, and G. Bezine, Fatigue propagation of two parallel cracks, Engineering Fracture Mechanics, 37 (1990) 1139-1144.

DOI: 10.1016/0013-7944(90)90034-e

[3] Z.D. Jiang, A. Zeghloul, G. Bezine, and J. Petit, Stress intensity factor of parallel cracks in a finite width sheet, Engineering Fracture Mechanics, 35 (1990) 1073-1079.

DOI: 10.1016/0013-7944(90)90135-4

[4] M. Kachanov, Continuum model of medium with cracks, Journal of the Engineering Mechanics Division, ASCE, 106 (1980) 1039-1051.

DOI: 10.1061/jmcea3.0002642

[5] M. Kachanov, E. L. E. Montagut, and J. P. Laures, Mechanics of crack-microcrack interactions, Mechanics of Materials, 10 (1990) 59-71.

DOI: 10.1016/0167-6636(90)90017-a

[6] M. Kamaya, Growth evaluation of multiple interacting surface cracks. Part I: Experiments and simulation of coalesced crack, Engineering Fracture Mechanics, 75(2008)1336-1349.

DOI: 10.1016/j.engfracmech.2007.07.015

[7] Y. -H. Chen and T. J. Lu, On the path dependence of the J-integral in notch problems, International Journal of Solids and Structures, 41(2004) 607-618.

DOI: 10.1016/j.ijsolstr.2003.10.007

[8] R. Daud, A. K. Ariffin, and S. Abdullah, Validation of Crack Interaction Limit Model for Parallel Edge Cracks using Two-Dimensional Finite Element Analysis, International Journal of Automotive and Mechanical Engineering, 7 (2013) 993-1004.

DOI: 10.15282/ijame.7.2012.15.0080

[9] J. R. Rice, A path independant integral and the approximate analysis of strain concentration by notches and cracks, Journal of Applied Mechanics, 35(1968) 379-386.

DOI: 10.1115/1.3601206

[10] A. E. Ismail, A. K. Ariffin, S. Abdullah, M. J. Ghazali, M. AbdulRazzaq, and R. Daud, Stress intensity factor under combined bending and torsion moments, Journal of Zhejiang University-SCIENCE A, 13(2012) 1-8.

DOI: 10.1631/jzus.a1100040
