The Comparison of the Variety of Finite Element Method (FEM) Based on the Arm of Mining Excavator

Abstract:

In this paper, authors made contrast with the three finite element methods in analysis accuracy and usability .Those are all based on the structural analysis of mining excavator arm. The first fem is using UG solid modeling capabilities to create model .The finite element model is generated by UG_ANSYS, including setting the loads of material properties and boundary conditions ,also loading work. The process is called preprocessing completely .Then export a“. inp” file,after that, imported that file directly into ANSYS software for solving. The second one is to import solid mode created in UG into ANSYS software directly ,then take pretreatment and solution accordingly.The last one is using UG modeling and UG NX NASTRAN (the finite element analysis function) for structure analysis. It is concluded that using UG completely pretreatment of ANSYS analysis method and UG NX NASTRAN method feel more convenient to operate it with the high analyze accuracy,with the two methods , designers can modify mining mechanical arm weak positions more easily.In turns,they can improve the designing level of physical prototyping.

• Periodical: Applied Mechanics and Materials (Volume 697)
• Pages: 173-176
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.697.173
• Online since: November 2014
• Authors: Hao Zou, Ming Zhang*, Jia Jun Ren
• Keywords: ANSYS, Movable Arm, NX NASTRAN, Pretreatment, Structure Analysis, UG

References

[1] Zhu Chong-gao Xie Fu-jun. UG NX CAE foundation and application instance: Beijing tsinghua university press, 2010. 10.

[2] Zhou Chang-cheng Hu Renxi. ANSYS 11. 0 basis and typical example: electronic industry press, 2007. 10.

[3] Gong Mian. Product related reference effect design technical training materials [M]. Shanghai: Shanghai engineering technology university press, (2004).

[4] Li Chun-wang. The air force engineering university faculty of science. ANSYS finite element analysis method based on UG pretreatment Journal of the air force engineering university , 5th, October , (2009).

[5] Cheng Kai Mechanical manufacturing and automation, tianjin university. Master thesis, CAE analysis method of complex mechanism research.

[6] Shen Jin, Li Chang-chun. Product parametric modeling technology based on UG/WAVE [J]. Modern design and advanced manufacturing technology, (2008).

[7] Zhu Jun-pu, bugles Northwestern polytechnical university institute of automation. Based on UG and ANSYS finite element analysis, the new technology, digital technology and mechanical engineering 2012. 6. 4.
