Effect of Tractor-Semitrailer Velocity on Cornering Braking Stability

Abstract:

A dynamic model of tractor-semitrailer cornering braking was established in this paper. The accuracy of the model was tested and verified by comparing model output with data of tractor-semitrailer test. By model simulation of the cornering braking process, initial speed such as 20km/h, 25km/h, 30km/h, 35km/h, 40km/h was chosen to analyzed the changing curve of braking distance, articulation angle, yaw rate and lateral acceleration. The result shows that during cornering braking of tractor-semitrailer, with the increasing of initial speed, braking distance greatly increased, articulation angle, yaw rate and lateral acceleration are all increasing. Thus, when braking in a turn, the vehicle speed must be reduced to ensure the stability of tractor-semitrailer cornering braking.

• Periodical: Applied Mechanics and Materials (Volume 697)
• Pages: 334-339
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.697.334
• Online since: November 2014
• Authors: Chen Li*, Shang Bin Song, Ge Teng Tang, Hui Qi Shi
• Keywords: Automotive Engineering, Cornering Braking, Stability, Tractor-Semitrailer, Velocity

References

[1] Guo Zhengkang. Design and Apply of Modern Tractor-Semitrailer[M]. Beijing: Beijing Institute of Technology Press, 2006, 6: 131.

[2] Song Nianxiu, Su Jian, Wang Dongjie, et al. Braking stability of tractor-semitrailer running on curve[J]. Journal of Traffic and Transportation Engineering, 2010, 10(1): 50-55. (in Chinese).

[3] Myung-Won Suh, Yoon-Ki Park, Seong-Jin Kwon et al. A Simulation Program for the Braking Characteristics of Tractor-Semitrailer Vehicle[J]. SAE Paper 2000-01-3415.

DOI: 10.4271/2000-01-3415

[4] Scott B. Zagorski, Dennis A. Guenther and Gary J. Heydinger. A Study of Jackknife Stability of Class Ⅷ Vehicles with Multiple Trailers with ABS Disc/Drum Brakes[J]. SAE Paper 2004-01-1741.

DOI: 10.4271/2004-01-1741

[5] The Vehicle Dynamics Committee. SAE670e 1976 Vehicle Dynamics Terminology[s]. Warrendate: SAE, (1976).

[6] Huang Jinchuan. Development and Application of Air Pressure ABS/ASR Hybrid Simulation System[D]. Beijing: Tsinghua University, (2006).

[7] Zhang Daisheng, Gu Qinlin, Chen Chaoyang. Simulation of Vehicle Antilock Braking System Based on Curved Braking[J]. Transactions of the Chinese Society for Agricultural Machinery, 2005, 36(9): 16-20. (in Chinese).
