Determination on the Effect of Cutter Geometrical Feature for Machining Polyetheretherketone (PEEK) Using Taguchi Methods

Abstract:

This paper details the application of Taguchi method to determine the effect of cutter geometrical features for machining Polyetheretherketones (PEEK) thermoplastic. The planned experiment was conducted by using Taguchi’s orthogonal array taking into account the ball nose geometrical parameters such as helix angle, rake angle, clearance angle and number of flute. The measured response is the machined surface roughness, which is important for the component functionality. In addition, ANOVA was used to validate the percentage contribution of each factor. The obtained results reveals that, less number of flutes is the main factor contributed towards fine surface roughness for this thermoplastic. Fewer flutes provide a smooth flow of chip ejection and minimize the friction on the cutting zone which is vital for polymeric material such as PEEK. High helix and rake angles also influence the machined surface roughness as both angles provide optimum shearing force to produced better surface finishing. However, it is found that clearance angle is less significant on roughness since the function of clearance angle is to control the process damping and stability. The main conclusion of this study is that there is significant effect on the cutter geometrical feature on machining performance and thus conclude the need of special design cutter for effectively machining PEEK plastic.

• Periodical: Applied Mechanics and Materials (Volume 699)
• Pages: 192-197
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.699.192
• Online since: November 2014
• Authors: Raja Izamshah*, Nurul Husna, Mohd Hadzley, Mohd Amran, Mohd Shahir Kasim, S. Amri
• Keywords: ANOVA, End Mill Geometry, Polyetheretherketones, Taguchi Method

References

[1] J. Sanderson, Y. Nakanishi, Polyetheretherketones in orthopaedic plate design to facilitate fracture recovery, J. of Biomechanical Sciences and Engineering 6(2) (2011) 125-133.

[2] Mata, F., Gaitonde, V.N., Karnik, S.R., Davim, J.P., Influence of cutting conditions on machinability aspects of PEEK, PEEK CF 30 and PEEK GF 30 composites using PCD tools, J. of Materials Progressing Technology, 209 (2009) 1980-(1987).

DOI: 10.1016/j.jmatprotec.2008.04.060

[3] Davim, J.P., Mata, F., Physical cutting model of Polyetheretherketone composites, Materials & Design, 27(10) (2006) 847–852.

DOI: 10.1016/j.matdes.2005.04.008

[4] Davim, J.P., Reis P., Lapa,V., Antonio, C.C., Machiniability study on polyetehretherketone (PEEK) unreinforced and reinforced (GF30) for applications in structural components. Composite Structure, 62 (2003) 67-73.

DOI: 10.1016/s0263-8223(03)00085-0

[5] Chatelain, J. and Zaghbani, I., Effect of tool geometry special features on cutting forces of multilayered CFRP laminates, Journal of Composite Materials (2012) 85–90.

[6] R. Izamshah, Yuhazri M Y, M Hadzley, M Amran, Sivarao, Effects of end mill helix angle on accuracy for machining thin-rib aerospace component, Applied Mechanics and , 315 (2013) 773-777.

DOI: 10.4028/www.scientific.net/amm.315.773

[7] Baldoukas, A.K., Soukatzidis, F.A., Demosthenous, G.A., Lontos, A.E., Experimental investigation of the effect of cutting depth, tool rake angle and workpiece material type on the main cutting force during a turning process, Proceedings of the 3rd International Conference on Manufacturing Engineering (ICMEN), 1-3 October (2008).

[8] Mata, F., Hanafi, I., Khamlichi, A., Jabbouri, A., Bezzazi, M., Derivation of statistical models to predict roughness parameters during machining process of PEEK composites using PCD and K10 tools, International Journal of Physical Science. 4(5) (2009).

[9] R. Izamshah, N. Husna, M. Hadzley, M. Amran, M. Shahir, M. Amri, Effects of cutter geometrical feature on machining polyetheretherketone (PEEK) engineering plastic, Proceedings of the 2nd International Conference on Mechanical Engineering (ICMER), 1-3 July (2013).

DOI: 10.15282/jmes.6.2014.12.0082

[10] Izamshah, R., John, P.T., Songlin, D., Hybrid deflection prediction on machining thin-wall monolithic aerospace components, Proceedings of the Institution of Mechanical Engineers, Part B: Journal of Engineering Manufacture. 226(4) (2012) 592-605.

DOI: 10.1177/0954405411425443
