Mixing Quality Improvement of a Coaxial Syngas Mixer by Adding Optimized Mechanical Tabs Using Three-Dimensional CFD Modeling

Abstract:

A coaxial gas mixer is designed for mixing air and synthesis gas or syngas as fuel. Three-dimensional computational models are harnessed to analyze and predict the influence of the mechanical tabs aspect ratio and number on the mixing characteristics and performance of the gas mixer. Attention is concentrated on the influence of mechanical tabs on the air-fuel ratio, pressure loss and mixing quality. The optimum design of the mechanical tab was realized with aspect ratio of 0.32 and 4 tabs with 45^o tab angle. The coaxial gas mixer using the optimized mechanical tabs was realized with λ of 1.13 corresponding to pressure loss of 37.2 Pa at 100 m³/h air-flow rates and the coefficient of variation (CoV) of mixing was 0.29. The gas mixer with the mechanical tabs had much better mixing performance than the gas mixer without mechanical tabs with only relatively small increase in pressure loss.

• Periodical: Applied Mechanics and Materials (Volume 699)
• Pages: 429-434
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.699.429
• Online since: November 2014
• Authors: Dominicus Danardono*, Ki Seong Kim
• Keywords: Air-Fuel Ratio, CFD, Coaxial Syngas Mixer, Mechanical Tabs, Mixing Quality, Pressure Loss

References

[1] A. Bakker, R.D. Laroche, Modeling of the turbulent flow in HEV static mixers, The Online CFM Book, (2000).

[2] Chemineer, Kenics, Static mixing technology, Chemineer Inc., Bulletin 800 (commercial documentation), (1998).

[3] S. Dong, H. Meng, Flow past a trapezoidal tab, Fluid Mech. 510 (2004) 219-242.

DOI: 10.1017/s0022112004009486

[4] A.W. Etchells III, C.F. Meyer, Mixing in pipelines, Handbook of Industrial Mixing: Science and Practice. John Wiley & Sons, Inc, New Jersey, (2004).

[5] C. Habchi, T. Lemenand, D.D. Valle, H. Peerhossaini, Turbulent mixing and residence time distribution in novel multifunctional heat echangers-reactors. Chemical engineering and processing: process intensification, (2010).

DOI: 10.1016/j.cep.2010.08.007

[6] H. Hu, T. Kobayashi, T. Saga, N. Taniguchi, Stereoscopic PIV Measurement of a jet flow with vortex generating tabs, The 10th International Symposium on Flow Visualization. (2002).

DOI: 10.1007/978-3-662-08263-8_25

[7] A. Mokrani, C. Castelain, H. Peerhossaini, Experimental study of the influence of the rows of vortex generators on turbulence structure in a tube, Chemical Engineering and Processing. 48 (2009) 659-671.

DOI: 10.1016/j.cep.2008.07.009

[8] S. Sundararaj, V. Selladurai, An analysis on proportional mixing of liquids using venturi jet mixer, International Journal of Applied Engineering Research. 7 (2008) 891-902.

[9] R.K. Thakur, Ch. Vial, K.D.P. Nigam, E.B. Nauman, G. Djelveh, Static mixer in the process industries – A review, Trans IchemE. 81 (2003).

DOI: 10.1205/026387603322302968

[10] T. Utomo, Z. Jin, M. Sq. Rahman, H. Jeong, H. Chung, Investigation on hydrodynamics and mass transfer characteristics of a gas-liquid ejector using three-dimensional CFD modeling, Journal of Mechanical Science and Technology. 22 (2008).

DOI: 10.1007/s12206-008-0614-3

[11] W. Yang, H. Meng, J. Sheng, Dynamics of hairpin vortices generated by a mixing tab in a channel flow, Experiments in Fluids. 30 (2001) 705-722.

DOI: 10.1007/s003480000252

[12] K.B.M.Q. Zaman, M.F. Reeder, M. Samimy, Control of an axisymmetric jet using vortex generators, Physics Fluids. 6 (2) (1994).

DOI: 10.1063/1.868316
