The Research of Flow Meter Dynamic Simulation Test

Abstract:

The flow signal is one of the main parameters of hydraulic system monitoring. Since the majority of fault features can be shown by dynamic traffic signal, The study of dynamic traffic signal has very important significance on the evaluation of the performance of hydraulic element and characteristics of the hydraulic system. In this paper, the flow meter dynamic signal was simulated by the self-designed test-bed called multi-functional gear flow meter speed detection test-bed. The experiment indicates that the using PLC control of inverter and motor can realize high frequency dynamic oscillating of gear, oscillation frequency can reach 2Hz above. If the accuracy is met with, flow meter dynamic characteristic can reach 10Hz through the test-bed simulation, which provides the basis of theory and experiment for the real-time dynamic flow characteristics test.

• Periodical: Applied Mechanics and Materials (Volume 703)
• Pages: 258-261
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.703.258
• Online since: December 2014
• Authors: Jun Zhang, Xue Xue Wang, Hong Mei Tang, Xian Hua Li, Meng Meng Niu
• Keywords: Dynamic Signal, Flow Meter, PLC Control

References

[1] Li Wenhong, Qiu Lihua, Wang Zhanlin. Study on Gear Flow Meter Dynamic Characteristics[J]. . China Mechanical Engineering2004, 15(18).

[2] Li Wenhong, Qiu Lihua, Wang Zhanlin, et al. On Dynamic Characteristic of Data Reconstruction Gear Flow Meter [J]. Control Engineering of China. 2004, 11(z1).

[3] Meng F, Zhou Z. The flow pulsation simulation for the new sine gears of flow meter[C]. Wuhan, China: IEEE Computer Society, (2011).

DOI: 10.1109/iceice.2011.5777767

[4] Zhang Guangming, Li Guo, Zhu Wei. Mechanical and electrical system of PLC control technology. Bei jing: National defence industry press.

[5] Xia Xiaoliang,. Multistage speed control in the application of PLC and frequency converter technology analysis [J]. Science and technology innovation and application of press. 2013(25).

[6] Wang Song, Zhang Tianhong, Wang Jianfeng, et al. Study of Dynamic Flow Rate Measurement Based on Turbine Flow Mete[J]. Measurement and Control Technology. 2012, 31(11).

[7] Cheng Zhang. Theoretical and Experimental Research of Multi-gear Flowmeter. AnHui University of Science and Technology, (2013).

[8] Zhang TEng. Research on three gear flowmeter [D]. AnHui University of Science and Technology, (2013).

[9] Wang Agen. Electrical programmable control principle and application (The second edition).

[10] Yang Zhigang, Liu Zhaoyan, Lei ZHenshan. Research of accuracy of flow measurement with virtual instrument [J]. Journal of Transducer Technology. 2004, 23(8).
