Study on Dynamic Characteristic in Hydraulic System Based on Bypass Method by the AMESim

Abstract:

s. At present, based on the bypass method to measurement the dynamic of the high pressure side flow in hydraulic system became more and more. In order to analysis the dynamic characteristics, the bypass method measurement system flow schematic was introduced in this paper, the dynamic flow of the main oil and the system was obtained by using dynamic flow of the side oil. Meanwhile, the dynamic pressure of the main oil was obtained by using dynamic pressure of the side oil. From the results of numerical analysis indicates that it is feasible to use the bypass method to get the characteristics of the dynamic flow and dynamic pressure in the system.

• Periodical: Applied Mechanics and Materials (Volume 703)
• Pages: 298-302
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.703.298
• Online since: December 2014
• Authors: Jun Zhang*, Yong Wu, Hong Mei Tang, Chun Ren Tang, Xian Hua Li
• Keywords: AMEsim, Dynamic Characteristic, Numerical Simulation, System Flow

References

[1] Yong-Ling Fu Hai-Tao Qi. LMS Imagine. Lab AMESim—tutorial system modeling and simulation examples [M]. Beijing: Beijing university of aeronautics and astronautics press, (2011).

[2] YU You-guan GONG Guo-fang HU Guo-liang. Simulation technique of AMESim and its application in hydraulic system [J]. HYDRAULICS PNEUMATICS & SEALS. 2005(3): 28-31.

[3] ZHENG Chang-ma WU Jian-feng MA Chong KONG Xiao-wu, et al. Research on the characteristic of PQ pump based on AMESim [J]. MECHANICAL & ELECTRICAL ENGINEERING MAGAZINE. 2010, 27(1): 59-61.

[4] DONG Chun-fang ZHU Yu-jie FENG Guo-hong. Study on Dynamical Simulation of Long Pipeline Hydraulic System Based on AMESim [J]. COAL MINE MACHINERY. 2010, 31(1): 73-75.

[5] WANG Biao ZHAO Jing-yi ZENG Hui CAO Wen-ao, et al. Design Simulation of a Two-phase Alternative Hydraulic System Based on AMESim [J]. HYDRAULICS PNEUMATICS & SEALS. 2010, 30(6): 8-9.

[6] ZHANG Da-bin SU Ming YAN Ji-duo YU Li-ya, et al. Digital Modeling of Hydraulic Axial Piston Pump and its Flux Pulsation Analysis Basing on AMESim [J]. COAL MINE MACHINERY. 2010, 31(1): 100-102.

[7] Clark C, Zamora M, Cheesewright R, et al. The dynamic performance of a new ultra-fast response Coriolis flow meter[J]. Flow Measurement and Instrumentation. 2006, 17(6): 391-398.

DOI: 10.1016/j.flowmeasinst.2006.07.002

[8] Rodrigues R J, Furlan R. Design of microsensor for gases and liquids flow measurements[C]. Elsevier Ltd, (2003).

[9] Chen Gang Zhou-Dong Fu Wu Gen mao, et al. Dynamic flow meter and intelligent optimization [J]. China Mechanical Engineering. 1994(3).

[10] Chen Gang Ma Yinliang Zhou-Dong Fu，et al. Dynamic flowmeter and its application [J]. Acta Metrologica Sinica. 1997(4).
