The Design of a Multi-Functional Force Loading Device

Abstract:

As a mechanical component, sensor can detect spatial information. Sensor technology has been widely used in national defense, aerospace, industrial inspection and automated production areas and so on. However, the sensor calibration device cannot meet the demand of the development of the sensor. In this paper, a multi-functional force loading device, which is of good technical performance, reliable operation, wide measurement range and simple measurement method, and a six-dimensional force sensor calibration method are described.

• Periodical: Applied Mechanics and Materials (Volume 709)
• Pages: 496-499
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.709.496
• Online since: December 2014
• Authors: Yu Qin Li, Ying Jun Li*, Huan Yong Cui, Gui Cong Wang, Xi Jie Tian
• Keywords: Calibration Device, Calibration Method, Force Sensor

References

[1] Qiang Xifu, Beijing, Machinery Industry Press, M. Sensors. (2001).

[2] Department of Aviation 304, The pilot test approach of the pressure sensor, s dynamic calibration, JJ0624-89. (1990).

[3] Huang Changyi, Yan Jinqiang, Mechanical Engineering Testing Technology, Beijing, Machinery Industry Press, (2001).

[4] Cui Yong. Stewart platform six-dimensional force sensor and the design of its calibration system, D. Yanshan Universit, (2006).
